NGK 8040 spark plug wire set for the 1995-1997 Honda Odyssey 4-cylinder 2.2L and other vehicles carries high-voltage current from the ignition to the spark plugs. This NGK wire set has four wires.
- Variable pitch winding over a ferrite magnetic alloy coating for low resistance and EMI/RFI noise suppression
- Outer jacket built to withstand temperatures greater than 250 degrees C, with EPDM or silicone inner insulation for dielectric strength
- Stainless steel terminals with up to 3 serrated crimps for terminal retention strength, wherever possible
- Locking C-shaped spring clip with corrosion-resistant plating for a secure spark plug terminal connection
- Spark plug boots glued to the cable with a silicone sealer for a watertight seal
- Cylinder lead identification tags, where possible, for easier installation
Quick facts
- Part: NGK 8040 spark plug wire set
- Fits: 1995-1997 Honda Odyssey 4-cylinder 2.2L and other vehicles
- Condition: New
Hard starting, a misfire, rough running, or a crack or burn mark on a jacket or boot can mean a wire has worn out, though worn spark plugs or a weak ignition coil may also lie behind those symptoms, so find the cause before replacing the set.
Fits
It fits the 1995-1997 Honda Odyssey 4-cylinder 2.2L and the 1996-1997 Isuzu Oasis 4-cylinder 2.2L, and each takes one set. The set is built to OEM tolerances.
Specifications
Fit and size
- Engine: L4-2.2L
- Quantity per vehicle: 1 set
- Wires in set: 4
Build and materials
- Cable type: variable pitch magnetic core
- Terminals: stainless steel
- Inner insulation: EPDM or silicone
- Outer jacket: withstands temperatures greater than 250 degrees C
- Condition: New
- Warranty: NGK limited lifetime warranty (see package for details)
- NGK part number: RC-HE80
Interchange: 175-6054 · 35-4215 · 671-4184 · 35-PF77436 · RC-HE80
86536 · CH7499 · CH7499U · 700800 · 09811 · 09830 · 9811 · 9830 · 9543 · 1274199U · 127499 · 164012 · 55010 · 7523
This part cross-references / interchanges with the following part numbers:
RC-HE80, 86536, CH7499, CH7499U, 175-6054, 700800, 09811, 09830, 9811, 9830, 35-4215, 671-4184, 9543, 8040, 1274199U, 127499, 35-PF77436, 164012, 55010, 7523
Frequently Asked Questions
Will the NGK 8040 wire set fit a 1996-1997 Isuzu Oasis 4-cylinder 2.2L?
Yes, NGK 8040 fits the 1996-1997 Isuzu Oasis 4-cylinder 2.2L, as it does the 1995-1997 Honda Odyssey 4-cylinder 2.2L, and each takes one set.
How many NGK plug wires are in this set?
This set has four wires, and the listing is one set. Each vehicle it fits takes one set.
Does this NGK wire have a magnetic core?
Yes. This set uses variable pitch magnetic core cables, wound over a ferrite magnetic alloy coating, for EMI/RFI noise suppression.
Are NGK spark plug wire sets covered by a warranty?
Yes. NGK 8040 comes with an NGK limited lifetime warranty; the package has the details.
What are the terminals on these NGK blue spark plug wires made of?
Stainless steel, with up to 3 serrated crimps that bite into the cable jacket and inner insulation for terminal retention strength, wherever possible.
