Nugeon 99-01736B rear left brake caliper for the 2011-2018 Toyota RAV4 clamps the pads against the rotor to slow that wheel. This Nugeon brake caliper is a remanufactured floating design.
- Single steel piston, 38 mm in diameter
- Aluminum caliper casting with a rust-preventative finish
- Banjo inlet fitting with an M10-1.0 x 23.4 port thread
- Bleeder screw with an M7-1.0 thread
Quick facts
- Part: Nugeon 99-01736B brake caliper
- Also called: disc brake caliper
- Fits: 2011-2018 Toyota RAV4
- Position: Rear left
- Material: Aluminum casting, steel piston
- Condition: Remanufactured
A worn or failing rear caliper can show up as brake fluid around the caliper, the car pulling to one side when you brake, or uneven pad wear. Worn pads or a stuck slide can look similar, so during a brake service, compare pad wear side to side and look at the piston boot before you decide on a caliper.
Fits
It is a 2011-2018 Toyota RAV4 brake caliper for the rear left wheel. This listing is one side; the rear right caliper is a separate part, and the other side of that axle is normally done at the same time.
Specifications
Fit and size
- Position: Rear left
- Quantity per vehicle: 1 (this side)
- Piston diameter: 38 mm (1.496 in)
- Piston quantity: 1
- Inlet fitting: Banjo, M10-1.0 x 23.4 port thread
- Bleeder screw thread: M7-1.0
- Housing cast number: 38 L
- Bracket cast number: L 3804
Build and materials
- Caliper type: Floating
- Condition: Remanufactured
- Casting material: Aluminum
- Piston material: Steel
- Finish: Rust preventative
- Country of origin: Mexico
In the box
One rear left brake caliper with its bracket, caliper slides, dust boots, caliper and pad hardware, bleeder screw and crush washers. Brake pads, anti-squeal shims, wear sensors, the bleeder screw cap and the bracket mounting bolts are not included, so plan on new mounting bolts. This listing holds one caliper for the rear left, which takes one; the rear right is ordered separately.
Frequently Asked Questions
Which side is this 2011-2018 Toyota RAV4 rear brake caliper for?
Nugeon 99-01736B is the rear left caliper. The rear right side is a separate part and is ordered on its own.
Does this Nugeon caliper come with brake pads?
No. It comes with the bracket, slides, dust boots, hardware and crush washers, but brake pads, anti-squeal shims and wear sensors are not included.
What size is the piston on this disc brake caliper?
Nugeon 99-01736B has one steel piston, 38 mm (1.496 in) across, in a floating caliper.
How can I tell if a rear brake caliper is leaking?
Brake fluid around the piston boot or on the caliper body can mean a leak. A leaking brake part should be checked promptly by a shop.
What thread does the inlet on this brake caliper use?
The banjo inlet port is M10-1.0 x 23.4. The bleeder screw that comes with the caliper is M7-1.0, and its cap is not included.
