Nugeon 99-02348B rear right brake caliper for the 2013-2015 BMW X1 and other vehicles clamps the brake pads against the rotor to slow the wheel. This remanufactured Nugeon brake caliper moves its piston under brake fluid pressure when you press the pedal.
- Floating caliper design with one piston
- Steel piston, 44 mm across, in a cast iron housing
- Rust-preventative finish on the caliper
- Bleeder screw with M8-1.25 thread and an M10-1.0 inlet port thread
Quick facts
- Part: Nugeon 99-02348B brake caliper
- Also called: disc brake caliper
- Fits: 2013-2015 BMW X1 and other vehicles
- Position: Rear right
- Material: Cast iron
- Condition: Remanufactured
A rear disc brake caliper that sticks or leaks can show up as the car pulling to one side, a burning smell after driving or brake fluid around the piston boot. These signs alone do not prove the caliper is at fault, since a collapsed brake hose can also drag a pad. Rear calipers sit one on each side of the axle and are normally replaced as a pair; this listing is the rear right one only, and the left is sold separately.
Fits
This rear right caliper is a direct-fit replacement for the 2013-2015 BMW X1, the 2007-2013 BMW 335i and the 2009-2013 BMW 335i xDrive, along with many other vehicles.
Specifications
Fit and size
- Position: Rear right
- Quantity per application: 1
- Pistons: 1, 44 mm (1.732 in) diameter
- Bleeder screw thread: M8-1.25
- Inlet port thread: M10-1.0
- Cast numbers: housing 44/22, 957; bracket 750
Build and materials
- Caliper type: Floating
- Piston material: Steel
- Casting material: Cast iron
- Finish: Rust preventative
- Condition: Remanufactured
- Country of origin: Mexico
In the box
One remanufactured brake caliper with its mounting bracket, caliper slides, dust boots, bleeder screw and crush washers. Brake pads, anti-squeal shims, wear sensors, the bleeder screw cap, the bracket mounting bolts and caliper and pad hardware are not included; plan on new bolts, as the old ones may not be reusable.
Frequently Asked Questions
Is this a 335i brake caliper for the 2007-2013 BMW 335i?
Yes, Nugeon 99-02348B fits the rear right of the 2007-2013 BMW 335i. If yours is a different BMW, look it up in the "Vehicles it fits" section.
Are these 2013-2015 BMW X1 calipers meant for the rear right side?
Yes. Nugeon 99-02348B is the rear right caliper for the 2013-2015 BMW X1, and the rear left caliper is sold separately.
Does the Nugeon caliper come with the mounting bracket?
Yes. This caliper includes the mounting bracket, caliper slides, dust boots, bleeder screw and crush washers. Pads, shims, wear sensors, the bleeder screw cap and bracket mounting bolts are not included.
What size is the piston on this rear right brake caliper?
This caliper has one steel piston that is 44 mm (1.732 in) across, in a floating caliper design.
Which cast numbers should I look for when matching my old caliper?
The housing is cast 44/22 and 957, and the bracket is cast 750. Compare them with the numbers on your old caliper.
