TERREPOWER 99P02116A rear right brake caliper for the 2000-2005 Volkswagen Passat and other vehicles clamps the brake pads against the rotor to slow the rear wheel. It is a remanufactured disc brake caliper, sold individually.
A caliper that sticks or leaks fluid can show up as the car pulling to one side, pads wearing unevenly or a burning smell after a drive. Before you replace it, rule out worn pads, a damaged brake hose and a seized slide, because other brake faults can feel much the same.
As a VW Passat brake caliper for the 2000-2005 model years, it goes on the rear right wheel, and it also fits the rear right of the 2001-2005 Audi Allroad Quattro and the 1998-2004 Audi A6 Quattro. That position takes one caliper; the rear left is a separate part ordered on its own, and the two sides are normally replaced together.
Fit and size
Build and materials
One brake caliper with its mounting bracket, caliper slides, dust boots, caliper and pad hardware, bleeder screw and crush washers. Brake pads, anti-squeal shims, wear sensors, bracket mounting bolts and the bleeder screw cap are not included, so plan on new bracket mounting bolts, as the old ones may not be reusable.
Is this a rear brake caliper for the 2000-2005 VW Passat?
Yes. TERREPOWER 99P02116A is the rear right caliper for the 2000-2005 Volkswagen Passat. The rear left side is a separate part.
Does this rear right caliper also fit the 2001-2005 Audi Allroad Quattro or the 1998-2004 Audi A6 Quattro?
Yes. TERREPOWER 99P02116A fits the rear right wheel of both the 2001-2005 Audi Allroad Quattro and the 1998-2004 Audi A6 Quattro.
Does this remanufactured caliper come with brake pads and bracket bolts?
No. Brake pads, bracket mounting bolts, anti-squeal shims and wear sensors are not included. The bracket, slides, dust boots, pad hardware, bleeder screw and crush washers are.
What thread sizes does this caliper have for the banjo inlet and bleeder screw?
The banjo inlet port thread is M12-1.0 x 20.9 mm and the bleeder screw thread is M10-1.0. The steel piston measures 38.07 mm across.
How can I tell a rear caliper may be sticking or leaking?
Brake fluid around the dust boot, pads worn unevenly or the car pulling to one side can be signs. If you notice any of them, have the brakes inspected promptly.
