TERREPOWER 99P18038B rear right brake caliper for the 2014-2023 Ford Transit Connect is a remanufactured unit that squeezes the brake pads against the rotor to slow the wheel. As a disc brake caliper, it turns hydraulic pressure into clamping force at the wheel.
- Floating caliper with one steel piston
- Aluminum casting
- E-coated finish
- Inlet fitting for a brake line, with M10 - 1.0 thread
Quick facts
- Part: TERREPOWER 99P18038B brake caliper
- Also called: disc brake caliper
- Fits: 2014-2023 Ford Transit Connect
- Position: Rear right
- Material: Aluminum
- Condition: Remanufactured
A sticking caliper can show up as the vehicle pulling to one side, uneven pad wear or fluid around the piston boot. A worn rotor, tired pads or a swollen brake hose can be behind those signs too, so find out which part is at fault before you buy a caliper.
Fits
Brake calipers are normally replaced as a pair across the axle, and this listing is a single rear right caliper; the rear left is a separate part. This caliper fits the 2014-2023 Ford Transit Connect, which takes one on the rear right.
Specifications
Fit and size
- Position: Rear right
- Quantity per vehicle: 1 for this side
- Piston diameter: 38 mm (1.496 in)
- Piston quantity: 1
- Bleeder screw thread: M10-1.0
Build and materials
- Caliper type: Floating
- Casting material: Aluminum
- Piston material: Steel
- Finish: E-coated
- Condition: Remanufactured
- Country of origin: Mexico
In the box
One caliper with its mounting bracket, caliper slides, dust boots, caliper and pad hardware, bleeder screw with cap and crush washers. Brake pads, anti-squeal shims, wear sensors and bracket mounting bolts are not included. Plan on new bracket bolts, since the old ones may not be reusable.
Interchange / FMSI:
FMSI: D1095
Frequently Asked Questions
Is the TERREPOWER 99P18038B brake caliper right for the 2014-2023 Ford Transit Connect?
Yes. The TERREPOWER 99P18038B is a rear right caliper for the 2014-2023 Ford Transit Connect. The rear left side is a separate part.
Does this rear right caliper come with the bracket and slides?
Yes. The TERREPOWER 99P18038B includes the mounting bracket, slides, dust boots, bleeder screw and cap, hardware and crush washers. Pads, shims, wear sensors and bracket bolts are not included.
What size is the piston on this floating caliper?
The caliper has one steel piston that measures 38 mm (1.496 in) across.
How can I tell if this rear brake caliper is sticking?
Signs can include the vehicle pulling to one side, uneven pad wear or a burning smell after driving. A shop can test the caliper, and any fluid around the boot calls for prompt attention.
Is the bleeder screw on this caliper a metric size?
Yes. The bleeder screw is M10-1.0 and comes with a cap.
