PowerStop AR85108 front brake rotor for the 2015-2020 Ford F-150 and other vehicles is the disc the pads clamp against to slow the wheel. It is sold individually.
- Power Stop AutoSpecialty line, standard replacement grade
- Manufactured to strict tolerances for DTV and runout, for smooth, quiet braking
- 100% dynamic mill balanced
- Cross-hatched finish on the friction surface for optimal pad break-in
Quick facts
- Part: PowerStop AR85108 brake rotor
- Also called: disc brake rotor
- Fits: 2015-2020 Ford F-150 and other vehicles
- Position: Front
- Condition: New
A pulsing brake pedal, grooves in the friction surface or a thickness at or under the discard limit can mean a disc brake rotor is worn. These signs alone do not prove the rotor is the problem, since a sticking caliper can produce similar symptoms.
Fits
It fits the 2010-2013 and 2015-2020 Ford F-150, the 2007-2021 Ford Expedition and the 2007-2022 Lincoln Navigator, and two of these rotors go on the front of each. This listing is one rotor, and both front sides are normally replaced together. It is a bolt-on replacement that needs no modifications, and its weight and vane count match the original equipment design.
Specifications
Fit and size
- Position: front
- Quantity per vehicle: 2
- Outside diameter: 350 mm (13.78 in)
- Bolt circle: 135 mm, 6 lug holes
- Nominal thickness: 34.60 mm (1.36 in)
- Discard thickness: 32.00 mm (1.26 in)
- Overall height: 49.50 mm
Build and materials
- Type: vented, full cast
- Grade: standard replacement
- Balancing: 100% dynamic mill balanced
- ABS tone ring: not included
- Condition: new
- Country of origin: China
In the box
One brake rotor. The ABS tone ring is not included.
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
What size is this PowerStop brake rotor?
PowerStop AR85108 measures 350 mm (13.78 in) across and is 34.60 mm thick new. It has a 135 mm bolt circle with 6 lug holes and a vented, full-cast body.
Do these F-150 brake rotors fit both the 2010-2013 and the 2015-2020 Ford F-150?
Yes. PowerStop AR85108 fits the 2010-2013 and the 2015-2020 Ford F-150 in the front position, and the front of each truck takes two.
Are PowerStop brake pads and rotors sold together in this listing?
No. This listing is one PowerStop AR85108 front rotor only. Brake pads are sold separately.
How thin can this front rotor get before it needs replacing?
This rotor is 34.60 mm (1.36 in) thick when new, and its discard thickness is 32.00 mm (1.26 in). One measuring at or below that is due for replacement.
Do these PowerStop front rotors come with an ABS tone ring?
No. This vented, full-cast front rotor does not include an ABS tone ring.
