Keep your 2014-2020 FIAT 500L braking smoothly with the Raybestos R-Line Front Disc Brake Rotor (MPN 781770R). Part of the R-Line program engineered for everyday driving, it drops in as a direct-fit front replacement for the listed application and is developed from OE samples for dependable stops.
This is a vented rotor with a smooth surface finish, a 12.008 in (305 mm) outside diameter, a 59 mm center bore, and 5 mounting bolt holes on a 98 mm bolt circle. Nominal thickness is 28.05 mm (1.104 in) with a 25.5 mm (1.004 in) discard thickness. No ABS tone ring is included. Country of origin: China. Sold individually — the FIAT 500L uses two front rotors, so order two and replace both sides as a matched pair for even, balanced braking. Manufacturer part number 781770R.
Will this rotor fit my vehicle?
It is a direct-fit front rotor for the 2014-2020 FIAT 500L (all engines). Check the Buyer's Guide tab to confirm your exact vehicle.
Is this a vented or solid rotor?
It is a vented rotor with a smooth surface finish, a 12.008 in (305 mm) outside diameter, a 59 mm center bore, and 5 mounting bolt holes on a 98 mm bolt circle.
How many rotors do I need?
This listing is for one rotor. The FIAT 500L uses two front rotors, so order two and replace both sides together as a matched pair for even, balanced braking.
Does it include an ABS tone ring?
No, this rotor does not include an ABS tone ring. Transfer or replace components as directed by the vehicle service procedure.
What is the discard thickness?
Nominal thickness is 28.05 mm (1.104 in) and the discard (minimum) thickness is 25.5 mm (1.004 in). Machine or replace the rotor per the service specification.
