Rear Differential Pinion Seal for 1998-2008 Chevrolet Tahoe & More - Schaeffler SS3119

$16.99

Schaeffler Differential Pinion Seal P/N:SS3119

Part number: SS3119

UPC: 670774264603

Condition: New

Weight: 0.15 LBS

Item Package Quantity: 1

$16.99

Current Stock: 36

Quantity:

Adding to cart… The item has been added

Have questions?

Ask an Expert

Schaeffler Differential Pinion Seal P/N:SS3119

$16.99

Description

Schaeffler SS3119 rear differential pinion seal for the 1998-2008 Chevrolet Tahoe and other vehicles is the shaft seal where the pinion shaft passes through the rear differential housing.

Holds lubricant in the differential and keeps dirt out at the pinion shaft
2.767 in (70.282 mm) outside diameter
2.125 in (53.975 mm) shaft diameter
Made for rear axles with an 8.50 in or 8.625 in ring gear

Oil streaks around the pinion, drips under the rear axle or a whine from the rear end can mean the seal is worn. A leaking axle cover gasket, a worn pinion bearing or a clogged axle vent can also be behind those signs, so find the cause before you buy a seal.

This rear differential pinion seal is a direct-fit part for the 1998-2015 GMC Yukon and the 1999-2008 Chevrolet Silverado 1500, as well as other rear-drive GM trucks and SUVs. For any other truck or SUV, look up its year and model in the "Vehicles it fits" section.

Specifications

Position: rear
Type: differential pinion shaft seal
Outside diameter: 2.767 in (70.282 mm)
Shaft diameter: 2.125 in (53.975 mm)
Ring gear size: 8.50 in or 8.625 in

Interchange: 710506 · 21285 · 4133119100

Manufacturer's description

Product specs

Vehicles it fits

Interchange numbers

This part cross-references / interchanges with the following part numbers:

710506, 21285, 4133119100

Buyer's Q&A

Frequently Asked Questions

Is the Schaeffler SS3119 the right rear pinion seal for a 1999-2008 Chevrolet Silverado 1500?

Yes. Schaeffler SS3119 is a rear differential pinion seal for the 1999-2008 Chevrolet Silverado 1500 and the 1998-2008 Chevrolet Tahoe.

What shaft size and outside diameter does the SS3119 pinion seal have?

This rear pinion seal fits a 2.125 in (53.975 mm) pinion shaft and measures 2.767 in (70.282 mm) across its outside diameter.

Does the SS3119 rear pinion seal work with an 8.625 in ring gear?

Yes. Schaeffler SS3119 is made for rear axles with an 8.50 in or 8.625 in ring gear on GM rear-drive trucks and SUVs.

How do I know if a rear differential pinion seal is leaking?

Oil spots under the rear axle, an oily dampness at the pinion or a whine from the rear end can be signs of a worn seal. A shop can inspect it to be sure.

Does the Schaeffler SS3119 interchange with 710506 or 21285?

Yes. 710506 and 21285 are interchange numbers for this rear differential pinion seal, along with 4133119100.
