Sealed Power Engine Piston Set P/N:285AP40 (Pack of 8)
$307.99
(You save)
Rebuild the V8-5.2L engine in your classic Chrysler or Dodge with the Sealed Power Engine Piston Set 285AP40 — a set of eight cast-aluminum pistons designed to help restore the performance and dependability of the original-equipment pistons. It's cataloged for a long list of 1967-1984 V8-5.2L applications, including the 1967-1978 Dodge Charger, 1968-1976 Dodge Dart, 1970-1974 Dodge Challenger, 1975-1983 Chrysler Cordoba, and 1977-1984 Dodge D150, W150 and Diplomat (see the Buyer's Guide tab for the full list).
Cast-aluminum construction: cast from high-quality aluminum with Sealed Power's FM132 eutectic proprietary alloy.
Premium flat-top head: premium-grade pistons with a flat piston head.
0.040" oversize: machined 0.040 in over standard bore (bore diameter 3.9063 in), so the block must be bored 0.040 in oversize to accept them.
Piston specs: piston pin outside diameter 0.9842 in (24.999 mm), compression height 1.720 in, pin offset 0.06 in; top and second compression rings 0.0781 in, oil ring 0.1875 in.
Built to OE standards: meets or exceeds OEM specifications using ISO- and QS-certified manufacturing.
Sold as a set of eight, matching the eight cylinders of the listed V8-5.2L applications. Assembly lubricant is not included. Country of origin: India. Manufacturer part number 285AP40.
This part cross-references / interchanges with the following part numbers:
P1516(8)040, 224-2007.040
Frequently Asked Questions
How many pistons come in this set?
The Sealed Power 285AP40 is a set of eight cast-aluminum pistons, matching the eight cylinders of the listed V8-5.2L applications.
Is this piston set oversized?
Yes. These pistons are machined 0.040 in over standard bore, so the engine block must be bored 0.040 in oversize to use them.
Will it fit my vehicle?
It's cataloged for many 1967-1984 Chrysler and Dodge V8-5.2L applications, such as the Charger, Dart, Challenger and D150. Check the Buyer's Guide tab for the full list.
Is assembly lubricant included?
No. Assembly lubricant is not included; consult the vehicle service information for the recommended assembly lube and the correct installation procedure.
What are the key piston specifications?
Flat-top head, piston pin outside diameter 0.9842 in (24.999 mm), compression height 1.720 in, pin offset 0.06 in, and a bore diameter of 3.9063 in.
