Sealed 310AP piston set for the 1962-1968 Chevrolet Impala V8 5.3L, the 1964-1968 Impala V8 5.4L and other vehicles gives a classic V8 rebuild a fresh set of cast aluminum pistons. The pistons are made to OEM-level specifications or better.
- Sealed Power Vintage line, made for restoring classic engines
- Cast from FM413 eutectic aluminum with 12% silicon for strength and durability
- High-quality aluminum casting and machining for reliability and long part life
- State-of-the-art manufacturing with exacting tolerances
- Up-tilt ring grooves improve piston-to-ring sealing and blow-by control
Quick facts
- Part: Sealed 310AP piston set
- Also called: engine piston set
- Fits: 1962-1968 Chevrolet Impala V8 5.3L, the 1964-1968 Impala V8 5.4L and other vehicles
- Material: Cast aluminum
- Condition: New
Blue exhaust smoke, low compression or a knocking noise from the engine can mean worn pistons, though worn piston rings or valve stem seals can produce the same signs. The 1962-1968 Chevrolet Impala V8 5.3L takes eight pistons.
Fits
This piston set is listed for a wide range of Chevrolet, Checker and Pontiac models, including the 1967-1968 Chevrolet Camaro V8 5.3L and the 1968 Camaro V8 5.4L, and the 1965-1969 Checker Marathon V8 5.3L and the 1968-1969 Marathon V8 5.4L.
Specifications
Fit and size
- Quantity per vehicle: 8
- Bore diameter: 4.0000 in
- Piston pin outside diameter: 0.9275 in
- Compression height: 1.654 in
- Top and second compression ring thickness: 0.078125 in each
- Oversized: No
Build and materials
- Piston material: Cast aluminum
- Piston head type: Recessed
- Grade type: Premium
- Condition: New
- Country of origin: India
In the box
The piston set. Assembly lubricant is not included.
Interchange: P3016(8)STD
TC1527 · 1423
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
TC1527, P3016(8)STD, 1423
Frequently Asked Questions
Is the Sealed 310AP right for a 1962-1968 Chevrolet Impala V8 5.3L?
Yes. Sealed 310AP fits the 1962-1968 Chevrolet Impala V8 5.3L and the 1964-1968 Impala V8 5.4L. If your car is not named here, look it up in the "Vehicles it fits" section.
Does the Sealed 310AP piston set come with assembly lubricant?
No. Assembly lubricant is not included with this piston set, so have your own ready for the build.
What bore size is this engine piston set made for?
Sealed 310AP is made for a 4.0000 in bore, with a 0.9275 in piston pin outside diameter and a 1.654 in compression height. It is not oversized.
What can I look for to tell if my pistons are worn?
Blue exhaust smoke, falling compression or a knock from the engine can be signs of worn pistons. A shop can measure piston and bore wear and run a compression test.
Does the Sealed 310AP replace TC1527?
Yes. TC1527 is one of the numbers Sealed 310AP replaces, along with P3016(8)STD and 1423.
