Sealed 517CP 30 piston set for the 1987-1992 Ford F-150 V8 5.0L and other vehicles carries combustion force to the connecting rod. This oversize set of cast aluminum pistons has a recessed head and aims at original equipment performance and dependability.
- DUROSHIELD skirt-coated piston
- Moly-graphite coating helps extend engine life
- Lower friction supports fuel economy and helps guard against scuffing and wear
- Helps improve cylinder sealing for less blow-by
- Helps prevent damage from inadequate lubrication on start-up
Quick facts
- Part: Sealed 517CP 30 piston set
- Also called: engine piston set
- Fits: 1987-1992 Ford F-150 V8 5.0L and other vehicles
- Material: Cast aluminum
- Condition: New
Heavy oil use, blue exhaust smoke, low compression or a knock from the cylinders can mean a worn engine piston set. Before you replace the pistons, rule out worn valve seals, tired rings and a leaking head gasket, because those can also explain oil use or low compression, and a shop can run the tests.
Fits
The 1987-1992 Ford F-150 V8 5.0L, the 1987-1992 Ford F-250 V8 5.0L and the 1987-1992 Ford Bronco V8 5.0L are covered by this piston set, and so are other vehicles. The 1987-1992 Ford Bronco V8 5.0L takes eight pistons. If your own model is not named here, open the "Vehicles it fits" section to check your exact model and engine.
Specifications
Fit and size
- Oversize: 0.030 in
- Bore diameter: 4.0000 in
- Piston pin outside diameter: 0.9122 in (23.17 mm)
- Compression height: 1.599 in
- Pin offset: 0.06 in (1.524 mm)
- Ring thickness: 1.50 mm top compression, 1.50 mm second compression, 4.00 mm oil
- Quantity per vehicle: 8
Build and materials
- Material: cast aluminum
- Construction: cast piston set
- Piston head type: recessed
- Coating: DUROSHIELD skirt coating, moly-graphite coating
- Condition: new
- Country of origin: India
Interchange: P3008(8)030
TC2587030 · 2242587030 · E7TZ6108L · 1195030 · Z30047030
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
TC2587030, 2242587030, P3008(8)030, E7TZ6108L, 1195030, Z30047030
Frequently Asked Questions
Does the Sealed 517CP 30 piston set fit the 1987-1992 Ford F-250 V8 5.0L?
Yes, Sealed 517CP 30 fits the 1987-1992 Ford F-250 V8 5.0L. For another model or engine, open the "Vehicles it fits" section.
How oversize is the Sealed 517CP 30 piston set?
Sealed 517CP 30 is 0.030 inch oversize, and its bore diameter is 4.0000 inch.
Do these cast aluminum pistons come with assembly lubricant?
No. Assembly lubricant is not included with this piston set, so plan on getting it separately.
What coating is on the skirt of these pistons?
The pistons are DUROSHIELD skirt-coated, and a moly-graphite coating reduces friction and helps guard against scuffing and wear.
What is the piston pin size on this 4.0000 inch bore set?
The piston pin outside diameter is 0.9122 inch (23.17 mm), with a 0.06 inch (1.524 mm) pin offset and a 1.599 inch compression height.
