Engine Piston for 1977-1996 Ford F-150 & More - Sealed H653CP 30

$311.99

Vehicles this part fits

    Part number: H653CP30
    UPC: 614046229082
    Condition: New
    Weight: 5.84 LBS
    Pack of 8
    $311.99
    Adding to cart… The item has been added

    Have questions?

    Sealed Power Engine Piston Set P/N:H653CP 30 (Pack of 8)
    Sealed Power Engine Piston Set P/N:H653CP 30 (Pack of 8)
    $311.99
    $311.99

    Sealed H653CP 30 engine piston for the 1977-1996 Ford F-150 V8 5.8L and other vehicles carries combustion force to the connecting rod. This cast piston set is a 0.030-inch oversize.

    • Helps improve cylinder sealing for less blow-by
    • Retains standard ring gaps in the top groove
    • DUROSHIELD skirt-coated piston
    • Moly-graphite coating that reduces friction for higher fuel economy
    • Coating helps prevent damage from inadequate lubrication on start-up

    Quick facts

    • Part: Sealed H653CP 30 engine piston
    • Fits: 1977-1996 Ford F-150 V8 5.8L and other vehicles
    • Material: Hypereutectic
    • Condition: New

    Heavy oil use, blow-by or low compression can mean a worn piston, but worn piston rings or a damaged cylinder wall could be behind them, so find the cause before you replace pistons.

    Fits

    The 1977-1996 Ford F-150 V8 5.8L, the 1977-1996 Ford F-250 V8 5.8L and the 1978-1996 Ford Bronco V8 5.8L take this piston, as do many other vehicles, and the engine takes eight. Open the "Vehicles it fits" section to check your exact model and engine.

    Specifications

    Fit and size

    • Quantity per vehicle: 8
    • Oversize: 0.030 in
    • Bore diameter: 4.0000 in
    • Piston pin outside diameter: 0.9122 in (23.17 mm)
    • Compression height: 1.765 in
    • Pin offset: 0.06 in (1.524 mm)
    • Top and second compression ring thickness: 0.0781 in
    • Oil ring thickness: 0.1875 in

    Build and materials

    • Piston material: Hypereutectic
    • Construction: Cast piston set
    • Piston head type: Recessed
    • Skirt coating: DUROSHIELD
    • Condition: New
    • Country of origin: Mexico

    In the box

    Assembly lubricant is not included.

    Interchange: P3046(8)030 · 224-2040.030

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    P3046(8)030, 224-2040.030

    Frequently Asked Questions

    Does the Sealed H653CP 30 piston fit a 1977-1996 Ford F-150 V8 5.8L?

    Yes. Sealed H653CP 30 fits the 1977-1996 Ford F-150 V8 5.8L, which takes eight. Other vehicles are covered too, so open the "Vehicles it fits" section for your exact model.

    What oversize is the H653CP 30 piston set?

    Sealed H653CP 30 is a 0.030 inch oversize cast piston set with a bore diameter of 4.0000 inches and a piston pin outside diameter of 0.9122 inch.

    What is the DUROSHIELD coating on these engine pistons?

    The skirt is DUROSHIELD-coated. The moly-graphite coating is designed to reduce friction and help guard against damage from inadequate lubrication on start-up.

    Does this piston set come with assembly lubricant?

    No. Assembly lubricant is not included with the Sealed H653CP 30 engine pistons.

    Does the H653CP 30 replace P3046(8)030?

    Yes. P3046(8)030 is one of the other numbers this engine piston replaces, along with 224-2040.030.
