Sealed H654CP 20 engine piston for the 1977-1995 Ford F-150 V8 5.0L and other vehicles transfers combustion pressure to the connecting rod. The listing is a cast engine piston set, oversize by 0.020 in.
- Helps improve cylinder sealing for less blow-by
- Retains standard ring gaps in the top groove
- DUROSHIELD skirt-coated piston
- Moly-graphite coating helps extend engine life
- Reduced friction to support fuel economy
- Helps protect against damage from inadequate lubrication on start-up
Quick facts
- Part: Sealed H654CP 20 engine piston
- Fits: 1977-1995 Ford F-150 V8 5.0L and other vehicles
- Material: Hypereutectic
- Condition: New
Heavy blow-by, burning oil or a knock from a cold engine can mean worn pistons, but worn piston rings or a worn cylinder bore may be behind them, so pin down the cause before you replace pistons.
Fits
This piston is listed for a wide range of Ford, Lincoln and Mercury models, led by the 1977-1995 Ford F-150 V8 5.0L, the 1987-1995 Ford Mustang V8 5.0L and the 1980-1995 Ford F-250 V8 5.0L, and that V8 takes eight pistons. If your car is not one of these, find its year and engine in the "Vehicles it fits" section.
Specifications
Fit and size
- Bore diameter: 4.0000 in
- Oversize: 0.020 in
- Quantity per vehicle: 8
- Compression height: 1.599 in
- Piston pin outside diameter: 0.9122 in (23.17 mm)
- Pin offset: 0.06 in (1.524 mm)
- Ring thickness: top and second compression 0.0781 in, oil 0.1875 in
Build and materials
- Piston material: Hypereutectic
- Head type: Recessed
- Skirt coating: DUROSHIELD
- Condition: New
- Country of origin: India
In the box
The engine piston set. Assembly lubricant is not included.
Interchange: P4112.20 · P1501(8)020 · 224-2108.020
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
P4112.20, P1501(8)020, 224-2108.020
Frequently Asked Questions
Will the Sealed H654CP 20 piston fit a 1987-1995 Ford Mustang V8 5.0L?
Yes. Sealed H654CP 20 is listed for the 1987-1995 Ford Mustang V8 5.0L as well as the 1977-1995 Ford F-150 V8 5.0L. Other cars are in the "Vehicles it fits" section.
Is the Sealed H654CP 20 piston set hypereutectic?
Yes. The piston material is hypereutectic, and the pistons have a recessed head and a DUROSHIELD skirt coating.
What oversize are these H654CP 20 pistons?
They are oversize by 0.020 in, with a 4.0000 in bore diameter. The piston pin outside diameter is 0.9122 in (23.17 mm).
Does the H654CP 20 piston set include assembly lubricant?
No. This set does not include assembly lubricant. The 5.0L V8 it is listed for takes eight pistons.
Do the Sealed Power H654CP 20 pistons have a coating?
Yes. These pistons are DUROSHIELD skirt-coated, and a moly-graphite coating is used to extend engine life and reduce friction.
