Sealed 1989YA engine piston wrist pin bushing set for the 1997-2008 Ford F-150 V8 5.4L, the 1997-2010 F-150 V8 4.6L, the 2011-2014 F-150 V8 5.0L and other vehicles gives the piston's wrist pin a bearing surface.
- Steel-backed bronze alloy lining
- Bronze alloy lining popular for fatigue resistance and strength
- Conformability that older engine applications require
Quick facts
- Part: Sealed 1989YA engine piston wrist pin bushing set
- Fits: the 1997-2008 Ford F-150 V8 5.4L, the 1997-2010 F-150 V8 4.6L, the 2011-2014 F-150 V8 5.0L and other vehicles
- Material: steel-backed bronze alloy lining
- Condition: New
A worn wrist pin bushing can show up as a metallic tick or knock from the engine. Worn wrist pins, pistons or connecting rods can be behind similar noises, so find the cause before you buy bushings. The bronze alloy lining offers less wear and corrosion resistance than other materials.
Fits
The 1996-2010 Ford Mustang V8 4.6L, the 2000 Mustang V8 5.4L, the 2011-2014 Mustang V8 5.0L and the 2002-2010 Ford Explorer V8 4.6L are among the many Ford, Lincoln and Mercury models this set fits. The V8 engines take eight bushings and the V10 6.8L engines take ten. If your vehicle isn't named here, enter its year and engine in the "Vehicles it fits" section.
Specifications
Fit and size
- Maximum inside diameter: 22.019 mm (0.8669 in)
- Maximum outside diameter: 24.150 mm (0.9508 in)
- Maximum length: 23.750 mm (0.9350 in)
Build and materials
- Lining: steel-backed bronze alloy
- Condition: New
- Country of origin: United States
Interchange: 2233620 · 2233679 · 5L3Z6207A · 7L3Z6207A · 8R3Z6207A · F3LY6207A
This part cross-references / interchanges with the following part numbers:
2233620, 2233679, 5L3Z6207A, 7L3Z6207A, 8R3Z6207A, F3LY6207A
Frequently Asked Questions
Does the Sealed 1989YA bushing set fit the 1997-2008 Ford F-150 V8 5.4L?
Yes. Sealed 1989YA fits the 1997-2008 Ford F-150 V8 5.4L, the 1997-2010 F-150 V8 4.6L and the 2011-2014 F-150 V8 5.0L. Each of those V8 engines takes eight bushings.
Is this wrist pin bushing set also listed for V10 6.8L engines?
Yes. The V10 6.8L engines in the fitment take ten bushings, while the V8 engines take eight. Check your engine in the "Vehicles it fits" section.
What size are the Sealed 1989YA wrist pin bushings?
The Sealed 1989YA set has a maximum inside diameter of 22.019 mm (0.8669 in), a maximum outside diameter of 24.150 mm (0.9508 in) and a maximum length of 23.750 mm (0.9350 in).
What are these piston wrist pin bushings made of?
They have a steel-backed bronze alloy lining, popular for fatigue resistance and strength. The lining also gives the conformability that older applications call for.
Does the Sealed 1989YA list 5L3Z6207A as an interchange number?
Yes. 5L3Z6207A is one of the other numbers this Sealed 1989YA set replaces. The Interchange line on the page gives the rest.
