Spark Plug for 1994-2001 Honda SA50 Elite SR & More - NGK 3419

$10.99
NGK NGK Iridium IX Spark Plug 3419
NGK NGK Iridium IX Spark Plug 3419

Vehicles this part fits
    Part number: 3419
    UPC: 087295134191
    Condition: New
    Weight: 0.12 LBS
    Item Package Quantity: 1
    $10.99
    Adding to cart… The item has been added

    Have questions?

    Ask an Expert
    NGK NGK Iridium IX Spark Plug P/N:3419
    NGK NGK Iridium IX Spark Plug P/N:3419
    $10.99
    $10.99

    NGK 3419 spark plug for the 1994-2001 Honda SA50 Elite SR 49cc and other vehicles ignites the air-fuel mixture with a 0.6 mm fine wire iridium tip. Among NGK spark plugs, it suits modified or high-performance applications, or works as an upgrade from OE nickel alloy plugs.

    • NGK Iridium IX line plug with a single iridium tip: 0.6 mm fine wire center electrode for high durability and a stable spark
    • Iridium alloy center electrode, with a density 6x that of platinum and a very high melting point
    • Tapered cut ground electrode with a reduced quenching design for ignitability and acceleration
    • Solid copper core, 98% pure copper, for heat dissipation, conductivity and a wide heat range
    • Trivalent metal plating that resists corrosion and seizing and eases installation and removal

    Quick facts

    • Part: NGK 3419 spark plug
    • Fits: 1994-2001 Honda SA50 Elite SR 49cc and other vehicles
    • Condition: New

    Hard starting, a rough idle or a misfire can mean worn spark plugs. These signs alone do not prove the spark plugs are at fault; a weak ignition coil is another common source.

    Fits

    The fit includes the 1994-2001 Honda SA50P Elite S 49cc and the 1978-1982 Yamaha LB50 Chappy 50cc, along with many other vehicles and equipment. Open the "Vehicles it fits" section to check your exact model and engine.

    Specifications

    Fit and size

    • Thread size: M14 - 1.25 (metric)
    • Reach: 12.7 mm (0.500 in)
    • Seat type: flat, with crush washer
    • Heat range: 6
    • Pre-gap: 0.8 mm (.032 in)
    • Quantity per vehicle: varies by engine

    Build and materials

    • Center electrode: copper core, fine wire iridium tip
    • Ground electrode: nickel, tapered cut, J-gap
    • Resistor type, 5000.0 ohms
    • Terminal: removable nut
    • Insulator material: ceramic
    • Country of origin: Japan
    • NGK part number: BR6HIX
    • Condition: new

    In the box

    One spark plug with its crush washer. The number a vehicle takes depends on the engine; the 1994-2001 Honda SA50 Elite SR 49cc takes one.

    Interchange: BR6HIX

    This part cross-references / interchanges with the following part numbers:

    BR6HIX

    Frequently Asked Questions

    Does the NGK 3419 spark plug fit the 1994-2001 Honda SA50P Elite S 49cc?

    Yes. NGK 3419 fits the 1994-2001 Honda SA50P Elite S 49cc, which takes one plug. For another model or engine, check the "Vehicles it fits" section.

    What thread size and reach does this NGK spark plug have?

    This spark plug has an M14 - 1.25 metric thread, a 12.7 mm (0.500 in) reach and a flat seat. It comes pre-gapped at 0.8 mm (.032 in).

    Why is the center electrode on NGK iridium spark plugs like this one made of iridium?

    Iridium's density is 6x that of platinum and its melting point is very high. This plug's 0.6 mm fine wire iridium tip supports high durability and a stable spark.

    Is this plug a resistor type, like NGK R spark plugs?

    Yes. NGK 3419 (BR6HIX) is a resistor-type plug, listed at 5000.0 ohms.

    Does the NGK Iridium IX spark plug come with a washer?

    Yes. NGK 3419 is sold as one plug with its crush washer. The number a vehicle takes depends on the engine.
