Spectra Premium CU1746 radiator for the 1995-1999 Toyota Avalon V6 3.0L and other vehicles moves heat out of the engine coolant as it flows through the core. Its structure and design are built for the same durability expectations as the OE radiator.
- Aluminum core with plastic tanks
- Down-flow layout with the inlet at the top right and the outlet at the bottom right
- Internal concentric transmission oil cooler with 10mm hose barb fittings
- Single core row, 1 inch thick
Quick facts
- Part: Spectra Premium CU1746 radiator
- Fits: 1995-1999 Toyota Avalon V6 3.0L and other vehicles
- Material: Aluminum core, plastic tanks
- Condition: New
Engine overheating or coolant stains under the car can mean a radiator is leaking or clogged. A thermostat, water pump, hose, radiator cap or cooling fan can be behind those signs too, so find the cause before you buy a new radiator.
Fits
It is a direct-fit replacement for the 1995-1999 Toyota Avalon V6 3.0L and the 1994-1996 Lexus ES300 V6 3.0L, and it is the Toyota Camry V6 3.0L radiator for the 1994-1996 model years. This listing is one radiator, and the 1995-1999 Toyota Avalon V6 3.0L takes one.
Specifications
Fit and size
- Quantity per vehicle: 1
- Core: 27.875 in wide, 16.75 in high, 1 in thick
- Inlet and outlet diameter: 1.3125 in
- Inlet and outlet header: 28.9375 in long, 1.875 in wide
- Transmission oil cooler fitting spacing: 14.75 in
- Mounting type: Bottom post / top saddle
Build and materials
- Core material: Aluminum
- Tank material: Plastic
- Core rows: 1
- Transmission oil cooler: Internal, concentric, 10mm hose barb fittings
- Frame: Not included
- Engine oil cooler: Not included
- Condition: New
- Country of origin: China
In the box
One radiator with its built-in transmission oil cooler. A frame and an engine oil cooler are not included.
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Does this Spectra Premium radiator fit the 1995-1999 Toyota Avalon V6 3.0L?
Yes. Spectra Premium CU1746 fits the 1995-1999 Toyota Avalon V6 3.0L, and each vehicle takes one radiator.
Can I use this as a 1994-1996 Toyota Camry V6 3.0L radiator replacement?
Yes. Spectra Premium CU1746 is a direct-fit replacement for the 1994-1996 Toyota Camry V6 3.0L, and this listing is one radiator.
Does this radiator have a built-in transmission oil cooler?
Yes. CU1746 has an internal concentric transmission oil cooler with 10mm hose barb fittings, spaced 14.75 in apart.
What size is the core on the CU1746 radiator?
The core is 27.875 in wide, 16.75 in high and 1 in thick, with 1.3125 in inlet and outlet diameters. Spectra Premium CU1746 has a single core row.
Does this radiator come with a frame?
No. A frame is not included with this radiator, and neither is an engine oil cooler.
