Standard Ignition S2113 sensor for the 2017-2023 Ford Mustang and other vehicles is an ABS wheel speed sensor connector with a wiring harness. It links the wheel speed sensor wiring to the rest of the harness.
- Weatherproof sealed plastic housing in an oval shape, with metal contact terminals
- Two female blade terminals with a push-on attachment
- Harness of two 16 ga. wires, 12.25 in long
- Quality checks and testing at every stage of production
Quick facts
- Part: Standard Ignition S2113 sensor
- Fits: 2017-2023 Ford Mustang and other vehicles
- Position: Front, rear, rear right, rear left
- Material: Plastic
- Condition: New
A cracked housing, corroded terminals or an ABS warning light can mean this connector is worn. The wheel speed sensor itself or a damaged tone ring can be behind the same light, so find the cause before replacing the connector.
Fits
The 2017-2023 Ford Mustang, the 2000-2007 Ford Focus and the 2015-2024 Ford Transit-150 are among the vehicles this connector fits. The quantity per vehicle varies by application, and this listing is one connector. If your car is not named here, open the "Vehicles it fits" section and look up your exact model and engine.
Specifications
Fit and size
- Position: front, rear, rear right, rear left
- Quantity per vehicle: varies by application
- Connector quantity: 1
- Wiring harness length: 12.25 in (311.15 mm)
- Wires: 2, 16 ga.
- Housing length: 1 1/4 in
Build and materials
- Material: plastic
- Contact terminal material: metal
- Connector shape: oval
- Terminals: 2, female blade, push-on attachment
- Weatherproof sealed: yes
- Splice connectors: 2 included
- Condition: new
- Country of origin: China
In the box
One connector with its wiring harness and two splice connectors. A dust shield is not included.
Installation notes
- The connector is factory-assembled for a simpler installation.
- No specialized tools are needed.
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Is the S2113 the right Ford Focus sensor connector for a 2000-2007 Ford Focus?
Yes, Standard Ignition S2113 fits the 2000-2007 Ford Focus. The Focus takes two or four depending on the application, and this listing is one connector.
Does the S2113 work as a Mustang sensor connector on the 2017-2023 Ford Mustang?
Yes, Standard Ignition S2113 fits the 2017-2023 Ford Mustang, and the Mustang takes two. For another model, look up its year and engine in the "Vehicles it fits" section.
Does the S2113 ABS connector come with wires and splice connectors?
Yes, it includes a wiring harness and two splice connectors. A dust shield is not included.
What wire gauge and harness length does this wheel speed sensor connector have?
The harness carries two 16 ga. wires and measures 12.25 in (311.15 mm). The housing is weatherproof sealed plastic with two female blade terminals.
Do I need special tools to install this ABS wheel speed sensor connector?
No. The connector is factory-assembled with a push-on attachment, and no specialized tools are needed to install it.
