Standard Ignition SC814 input shaft speed sensor for the 2017-2019 Hyundai Sonata and other vehicles monitors how fast the transmission input shaft turns. It is a new sensor for automatic transmissions.
- Designed to support smooth transmission shifting and proper cruise control function
- Materials chosen to withstand extreme conditions, gunk and transmission fluid contamination
- Extensive quality assurance testing to check reliability
- Designed to address the inherent failure issues of original sensors
Quick facts
- Part: Standard Ignition SC814 input shaft speed sensor
- Also called: input speed sensor
- Fits: 2017-2019 Hyundai Sonata and other vehicles
- Condition: New
A failing sensor can show up as harsh or erratic shifts, a cruise control that will not hold speed or a warning light. Several other faults produce those symptoms too, so before replacing it, look over the connector and wiring with the engine off for damage, fluid or corrosion; a shop can test the signal itself.
Fits
It is a direct-fit OE replacement listed for a wide range of Hyundai and Kia models, including the 2018-2020 Kia Sorento and the 2019-2020 Hyundai Santa Fe. This listing is one sensor, and a 2017-2019 Hyundai Sonata takes one.
Specifications
Fit and size
- Quantity per vehicle: 1
- Mounting location: transmission
- Mounting type: push on
- Number of bolt holes: 2
- Connector quantity: 1
- Terminal quantity: 6
Build and materials
- Condition: New
- Connector: plug-in, female
- Terminals: male, blade
- Country of origin: Viet Nam
In the box
One input shaft speed sensor. Mounting hardware and a dust shield are not included, and the old fasteners may not be reusable, so plan on new ones.
Interchange: SN8516 · VSSB10136 · VSS1348 · 426204G200
This part cross-references / interchanges with the following part numbers:
SN8516, VSSB10136, VSS1348, 426204G200, SC814
Frequently Asked Questions
Is the Standard Ignition SC814 input speed sensor right for the 2018-2020 Kia Sorento?
Yes, the Standard Ignition SC814 is listed for the 2018-2020 Kia Sorento. If your car is not named on this page, look it up in the "Vehicles it fits" section and match the year.
Does the SC814 input shaft speed sensor come with mounting hardware?
No. The Standard Ignition SC814 is one sensor only; mounting hardware and a dust shield are not included, so plan on new fasteners.
How many terminals does the SC814 connector have?
The connector is a female plug-in type with six male blade terminals. The sensor also has two bolt holes.
Could erratic shifting or a cruise control that won't hold come from a bad input shaft speed sensor?
Yes, either sign can come from a faulty speed sensor, but other parts can cause both too. A shop scan can help narrow it down.
Does the Standard Ignition SC814 replace part number 426204G200?
Yes, 426204G200 is an interchange number for the Standard Ignition SC814, along with SN8516, VSSB10136 and VSS1348.
