Standard DWS1769 front right door lock switch for the 2010-2013 Hyundai Elantra controls the passenger window up and down and includes lock and unlock. It works as a power window switch, not a master switch.
- Copper alloy conductors for electrical conductivity with low resistive losses
- Tested for both mechanical and electrical switching performance
- Two switches: passenger window up/down control, with lock/unlock included
- Illuminated switch
- Rectangular female connector with 9 male blade terminals, 12V
Quick facts
- Part: Standard DWS1769 door lock switch
- Fits: 2010-2013 Hyundai Elantra
- Position: Front right
- Material: Plastic
- Condition: New
A passenger window that moves slowly or not at all, lock and unlock that do not respond, or a switch that works only now and then can mean the switch is worn. A window motor, window regulator, fuse, wiring or door-lock actuator can be behind the same signs too, so find the cause before buying a switch.
Fits
This switch is specifically designed for Hyundai and is engineered as an OE replacement for the 2010-2013 Hyundai Elantra.
Specifications
Fit and size
- Position: Front right
- Quantity per vehicle: 1
- Connector: 1 rectangular, female
- Terminals: 9 male blade
- Attachment method: Push on
- Voltage: 12V
Build and materials
- Material: Plastic
- Color: Black
- Number of switches: 2
- Window up/down controls: Passenger
- Lock/unlock: Included
- Illuminated: Yes
- Master switch: No
- Condition: New
- Country of origin: Republic of Korea
In the box
One door lock switch. A wiring harness and mounting hardware are not included, and old fasteners may not be reusable. This listing is one switch for the front right door, and that door takes one; the front left is a separate part.
Interchange: WST1869 · SW10666 · PA4639 · 5753X100RY · 935753X100RY
This part cross-references / interchanges with the following part numbers:
WST1869, SW10666, PA4639, 5753X100RY, 935753X100RY, DWS1769
