Standard Ignition UF-15 ignition coil for the 1993 Aston Martin Virage V8 5.3L and other vehicles steps 12-volt battery voltage up to the high voltage a spark plug needs. This electronic coil is oil filled and has two male screw terminals.
- Full E-Lam core of silicon steel
- Solid brass high-voltage terminals that protect against corrosion
- 100% pure copper windings in the primary and secondary bobbins for durability and resistance to internal shorts and dielectric breakdown
- Special blended formula that helps with heat dissipation
- Primary and secondary windings of enamel magnet wire for a high temperature rating
Quick facts
- Part: Standard Ignition UF-15 ignition coil
- Fits: 1993 Aston Martin Virage V8 5.3L and other vehicles
- Condition: New
A hard start, a misfire or a rough idle can be signs of a failing ignition coil. Worn spark plugs, damaged plug wires or a fuel delivery fault can be behind the same signs, so find the cause before buying. If the coil is the cause, this one replaces it.
Fits
The 1993 Aston Martin Virage V8 5.3L, the 1981-1992 Jaguar XJ12 V12 5.3L and the 1979-1989 Aston Martin Lagonda V8 5.3L are among the cars this coil fits, along with many other vehicles.
Specifications
Fit and size
- Quantity per vehicle: 1
- Voltage: 12 V
- Terminals: 2, male, screw type
- Connectors: 2, male
- Mount type: bolt on
- Mounting location: fender
Build and materials
- Ignition type: oil filled
- Core: full E-Lam silicon steel
- High-voltage terminals: solid brass
- Windings: 100% pure copper, enamel magnet wire
- Condition: New
- Country of origin: United Kingdom
In the box
One ignition coil comes in this listing, and a vehicle takes one. Mounting hardware and a mounting bracket are not included, so plan on new fasteners because the old ones may not be reusable.
Interchange: E521 · IGNC20018 · IC274 · DLB170
This part cross-references / interchanges with the following part numbers:
E521, IGNC20018, IC274, DLB170, UF-15
Frequently Asked Questions
Does the Standard Ignition UF-15 fit a 1981-1992 Jaguar XJ12 V12 5.3L?
Yes. Standard Ignition UF-15 fits the 1981-1992 Jaguar XJ12 V12 5.3L. If your car is a different one, look it up in the "Vehicles it fits" section on this page.
Is this Standard Ignition coil oil filled?
Yes. Standard Ignition UF-15 is an oil-filled electronic ignition coil with a 12-volt rating.
Does the UF-15 come with a mounting bracket?
No. This listing is one ignition coil; mounting hardware and a mounting bracket are not included.
What are the windings in this ignition coil made of?
The primary and secondary bobbins have 100% pure copper windings, and the windings use enamel magnet wire. The core is a full E-Lam core of silicon steel.
What kind of terminals does the UF-15 have?
This ignition coil has two male screw terminals and two male connectors. The high-voltage terminals are solid brass.
