Ignition Control Module for 1988-1997 Ford F-250 & More - Standard Ignition LX-226

$111.99
WARNING:California Proposition 65▾

Vehicles this part fits

    Part number: LX-226
    UPC: 091769017989
    Condition: New
    Weight: 0.18 LBS
    Item Package Quantity: 1
    $111.99
    Adding to cart… The item has been added

    Have questions?

    Standard Ignition Ignition Control Module P/N:LX-226
    Standard Ignition Ignition Control Module P/N:LX-226
    $111.99
    $111.99

    Standard Ignition LX-226 ignition control module for the 1988-1996 Ford F-250 V8 7.5L, the 1991 F-250 6-cylinder 4.9L, the 1992-1996 F-250 V8 5.0L, the 1992-1997 F-250 V8 5.8L and other vehicles energizes the ignition coils on a distributorless ignition system. It is designed to fix the inherent failure issues of the original equipment module.

    • Copper slug heat sinks improve heat dissipation to keep heat from damaging the module
    • High-temperature polymer housing reduces moisture intrusion and minimizes vibration damage
    • Double wire bonds for dependable connections and longer life under intense vibration and a tough operating environment
    • Durability tested for 500 thermal cycles from -40C to +125C
    • Responds to a weak crankshaft position sensor signal and energizes the coils immediately for cold-weather starts

    Quick facts

    • Part: Standard Ignition LX-226 ignition control module
    • Fits: 1988-1996 Ford F-250 V8 7.5L, the 1991 F-250 6-cylinder 4.9L, the 1992-1996 F-250 V8 5.0L, the 1992-1997 F-250 V8 5.8L and other vehicles
    • Condition: New

    Hard starting, stalling or a misfire can mean the module is wearing out. These signs alone do not prove it is the problem, since a weak ignition coil can lead to similar symptoms. The 1988-1996 Ford F-250 V8 7.5L takes one module.

    Fits

    This module is listed for a wide range of Ford models, including the 1991 Ford F-150 6-cylinder 4.9L, the 1992-1996 F-150 V8 5.0L or 5.8L, the 1990-1991 Ford Bronco 6-cylinder 4.9L and the 1992-1996 Bronco V8 5.0L or 5.8L. If your vehicle is not named here, look up its year and engine in the "Vehicles it fits" section.

    Specifications

    Fit and size

    • Quantity per vehicle: 1
    • Voltage: 12 V
    • Terminals: 6, male blade
    • Connector: 1, female
    • Mounting location: external
    • Attachment method: bolt on

    Build and materials

    • Ignition type: distributorless
    • Housing: high-temperature polymer
    • Heat sinks: copper slug
    • Condition: New
    • Country of origin: United States

    In the box

    One ignition control module. Mounting hardware is not included, so plan on new bolts.

    Product information is for general reference and may contain errors. See our Disclaimer.

    Frequently Asked Questions

    Does the Standard Ignition LX-226 work as a Bronco ignition control module for the 1992-1996 Ford Bronco V8 5.0L?

    Yes. Standard Ignition LX-226 is listed for the 1990-1991 Ford Bronco 6-cylinder 4.9L and the 1992-1996 Bronco V8 5.0L or 5.8L. For other trucks, check the "Vehicles it fits" section.

    Do I need to buy bolts separately for the Standard Ignition LX-226 ignition control module?

    Yes. Standard Ignition LX-226 is one bolt-on module and mounting hardware is not included, so plan on new bolts.

    What connector does this ignition control module use?

    It has one female connector with six male blade terminals. The module runs on 12 volts and mounts externally.

    What temperature testing does this ignition control module go through?

    It is durability tested for 500 thermal cycles from -40C to +125C. Copper slug heat sinks help carry heat away from the module.

    Will this Standard Ignition LX-226 module help with cold-weather starting?

    Standard Ignition LX-226 responds to a weak crankshaft position sensor signal and starts energizing the coils right away. That is designed to give better starts in cold weather.
