Ignition Control Module for 1991-2005 Acura NSX & More - Standard Ignition LX-747

$824.99

Vehicles this part fits

    Part number: LX-747
    UPC: 091769330460
    Condition: New
    Weight: 0.40 LBS
    Item Package Quantity: 1
    $824.99
    Adding to cart… The item has been added

    Have questions?

    Standard Ignition Ignition Control Module P/N:LX-747
    Standard Ignition Ignition Control Module P/N:LX-747
    $824.99
    $824.99

    Standard Ignition LX-747 ignition control module for the 1991-2005 Acura NSX V6 3.0L, the 1997-2005 NSX V6 3.2L and other vehicles switches the ignition coils in a distributorless ignition system. When an original module fails, this one is designed to fix the inherent failure issues.

    • Copper slug heat sinks that dissipate heat to protect the module from heat damage
    • High-temperature polymer housing that reduces moisture intrusion and minimizes vibration damage
    • Double wire bonds for dependable connections under intense vibration
    • Durability tested for 500 thermal cycles ranging from -40C to +125C
    • Responds to a weak crankshaft position sensor signal and starts energizing the coils at once for cold-weather starts

    Quick facts

    • Part: Standard Ignition LX-747 ignition control module
    • Fits: the 1991-2005 Acura NSX V6 3.0L, the 1997-2005 NSX V6 3.2L and other vehicles

    Hard starting, a no-start or a misfire can mean the module is failing. Worn ignition coils, a weak crankshaft position sensor or damaged wiring can produce those signs too, so find which one is at fault before you buy a module.

    Fits

    A direct-fit replacement for a wide range of Acura models, it is listed for the 1996-2004 Acura RL V6 3.5L and the 1996-1998 Acura TL V6 3.2L among others. This listing is one module, and the 1996-2004 Acura RL V6 3.5L takes one. Open the "Vehicles it fits" section to check your exact model and engine.

    Specifications

    Fit and size

    • Quantity per vehicle: 1
    • Voltage: 12 V
    • Attachment method: Bolt on
    • Ignition type: Distributorless

    Build and materials

    • Terminals: 8 male blade terminals
    • Connectors: 2, female
    • Country of origin: Japan

    In the box

    One ignition control module. Mounting hardware, a mounting bracket, instructions and the ignition coil are not included, so plan on new bolts rather than reusing the old ones.

    Interchange: 30120PR7A01 · CBE719 · JH152 · TP326

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    30120PR7A01, CBE719, JH152, TP326, LX-747

    Frequently Asked Questions

    Does the Standard Ignition LX-747 fit the 1996-2004 Acura RL V6 3.5L?

    Yes, Standard Ignition LX-747 is a direct-fit replacement for the 1996-2004 Acura RL V6 3.5L; open the "Vehicles it fits" section to check other models and engines.

    Does the LX-747 ignition control module come with a bracket or bolts?

    No. Standard Ignition LX-747 is the module alone; mounting hardware, a mounting bracket, instructions and the ignition coil are not included.

    What connectors and terminals does this ignition control module have?

    This ignition control module has two female connectors and eight male blade terminals. It runs on 12 volts and attaches with bolts.

    How is this ignition control module tested for heat and cold?

    This ignition control module is durability tested for 500 thermal cycles ranging from -40C to +125C. Copper slug heat sinks dissipate heat to protect the module.

    Is the Standard Ignition LX-747 interchangeable with number 30120PR7A01?

    Yes. 30120PR7A01 is a number this module replaces, so Standard Ignition LX-747 can be matched against it.
