Monroe Shocks & Struts 172548 front left strut assembly for the 2004-2010 BMW X3 damps wheel movement and supports the coil spring. Also called a complete strut and coil spring assembly, it is fit checked and ride tested for this vehicle.
- Monroe Quick-Strut line: strut, coil spring and upper strut mount supplied as a single assembled unit
- Coil spring type engineered to restore ride height and support the vehicle's weight
- Application-specific coil spring, mount and strut designs for the ride and handling of each vehicle
- Reduces body sway, vibration and road harshness before it reaches the passenger cabin
- Upper strut mount helps keep steering precise and limits noise, vibration, harshness and memory steer
- Protective coating resists rust and corrosion and is salt spray tested
Quick facts
- Part: Monroe Shocks & Struts 172548 strut assembly
- Also called: complete strut and coil spring assembly
- Fits: 2004-2010 BMW X3
- Position: Front left
- Condition: New
A worn strut can show up as a bouncy ride after bumps, nose dive under braking or uneven tire wear. Before you replace the assembly, rule out worn tires, loose sway bar links and worn control arm bushings, since each of those can also give a clunk or an unsettled ride.
Fits
It fits the 2004-2010 BMW X3. Replace the front struts as a pair, one on each side of the axle; this listing is the front left strut only, and the front right is ordered separately.
Specifications
Fit and size
- Position: front left
- Quantity per vehicle: 1 for this side
- Compressed length: 12.48 in (317 mm)
- Extended length: 19.21 in (487.9 mm)
- Travel length: 6.73 in
- Body length: 11.98 in
Build and materials
- Type: gas-charged, passive suspension
- Compression and ride height: not adjustable
- Finish: protective rust-resistant coating
- Condition: new
- Warranty: Monroe Limited Lifetime Warranty
- Country of origin: China
In the box
One front left strut assembly with the coil spring, strut mount, coil spring insulator and strut mount insulator included, plus mounting hardware.
Installation notes
- No spring compressor is needed because the spring comes assembled with the strut.
Interchange: LS5495651L · 33BW1103
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
LS5495651L, 33BW1103, 172548
Frequently Asked Questions
Is the Monroe Quick-Strut 172548 the right front left strut for a 2004-2010 BMW X3?
Yes. Monroe Shocks & Struts 172548 fits the front left of the 2004-2010 BMW X3. The front right side is a separate strut ordered on its own.
Does the Monroe 172548 come with the coil spring and upper mount?
Yes. Monroe Shocks & Struts 172548 comes with the coil spring, strut mount, both insulators and mounting hardware already included.
How long is this strut assembly compressed and extended?
It measures 12.48 in (317 mm) compressed and 19.21 in (487.9 mm) extended, with 6.73 in of travel.
How can I tell if my front strut is worn out?
You may notice bouncing after bumps, nose dive when braking or uneven tire wear. These signs can have other causes, so a shop can confirm the strut.
Do I need a spring compressor to install the Monroe 172548?
No. The Monroe 172548 arrives as an assembled unit with the coil spring already on the strut, so no spring compressor is needed.
