Monroe Shocks & Struts 173061 front left strut assembly for the 2016-2017 Chevrolet Cruze replaces the strut, coil spring and upper strut mount as one preassembled unit. The strut damps spring movement while the coil spring supports the vehicle's weight at that corner.
- Quick-Strut unit arrives fully assembled, so no spring compressor is needed
- Coil spring engineered to restore ride height and support the vehicle's weight
- Application-specific coil spring, mount and strut designs for each vehicle profile
- Reduces body sway, vibration and road harshness before it reaches the passenger cabin
- Upper strut mount helps keep steering precise and prevents noise, vibration, harshness and memory steer
- Protective coating resists rust and corrosion, and the part is salt spray tested
Quick facts
- Part: Monroe Shocks & Struts 173061 strut assembly
- Also called: complete strut and coil spring assembly
- Fits: 2016-2017 Chevrolet Cruze
- Position: Front left
- Condition: New
A leaking strut body, a bouncy or nose-diving ride, a clunk over bumps or uneven tire wear can mean a strut is worn. Worn control arm bushings, sway bar links, ball joints or tires can be behind those signs too, so find the cause before you buy a strut.
Fits
This listing is one strut assembly for the front left of the 2016-2017 Chevrolet Cruze, which takes one on that side. The front right is a separate part, and the two front struts are normally replaced at the same time.
Specifications
Fit and size
- Position: front left
- Quantity: 1 for the front left (the front right is a separate part)
- Compressed length: 13.91 in (353.3 mm)
- Extended length: 20.64 in (524.3 mm)
- Travel length: 6.73 in
- Body length: 14.33 in
Build and materials
- Type: gas charged, passive suspension
- Adjustable compression: no
- Adjustable ride height: no
- Finish: protective coating
- Condition: new
- Warranty: Monroe Limited Lifetime Warranty
- Country of origin: China
In the box
One front left strut assembly with coil spring, upper strut mount, coil spring insulator, strut mount insulator and mounting hardware.
Interchange: LS3381941L · 33GM1195 · 92141012
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
LS3381941L, 33GM1195, 173061, 92141012
Frequently Asked Questions
Does the Monroe Quick-Strut 173061 fit the 2016-2017 Chevrolet Cruze?
Yes. Monroe Shocks & Struts 173061 is a front left strut assembly for the 2016-2017 Chevrolet Cruze. The front right side is a separate part.
What comes with this complete strut and coil spring assembly?
Monroe 173061 includes the strut, coil spring, upper strut mount, coil spring insulator, strut mount insulator and mounting hardware, all in one unit.
How long is the Monroe 173061 strut when compressed and extended?
Compressed length is 13.91 in (353.3 mm) and extended length is 20.64 in (524.3 mm). Travel length is 6.73 in and body length is 14.33 in.
What should I look for on a worn front strut assembly?
With the engine off and the car parked, look for oily film on the strut body, a rusted or broken coil spring or a cracked upper mount. A bouncy ride or a clunk over bumps can also mean wear.
Does Monroe 173061 replace the 33GM1195 number?
Yes. 33GM1195 is one of the cross-reference numbers listed for Monroe Shocks & Struts 173061, along with LS3381941L and 92141012.
