TERREPOWER 930-0105 power steering pump for the 1998-2002 Toyota Corolla and other vehicles is a remanufactured hydraulic pump that builds the fluid pressure behind power-assisted steering. The engine drives it, and it sends pressurized fluid to the steering gear so the wheel turns with less effort.
- Housing made of aluminum and cast iron
- Splined pulley attachment
- Banjo bolt outlet with an M16X1.50 thread
- Pipe-type inlet connection with one inlet
- Three mounting holes
- Installation kit included
Quick facts
- Part: TERREPOWER 930-0105 power steering pump
- Fits: 1998-2002 Toyota Corolla and other vehicles
- Material: Aluminum, Cast Iron
- Condition: Remanufactured
A whine when turning, heavy steering effort or fluid seepage at the pump can mean the pump is worn, though a slipping drive belt or a leaking pressure hose can be behind the same signs.
Fits
It is a direct-fit power steering pump replacement for the 1998-2002 Toyota Corolla and the 2000-2002 Chevrolet Prizm.
Specifications
Fit and size
- Quantity per vehicle: 1
- Mounting holes: 3
- Outlet thread size: M16X1.50
- Outlet diameter: 16 mm
- Thread diameter: 8 mm
- Inlet quantity: 1
Build and materials
- Type: hydraulic, remote reservoir
- Condition: remanufactured
- Housing material: aluminum, cast iron
- Outlet attachment: banjo bolt
- Inlet attachment: pipe
- Pulley attachment: splined
- Country of origin: Mexico
In the box
One remanufactured power steering pump with an installation kit; a car needs one pump. The pulley, reservoir, reservoir cap and filter are not included.
Interchange: 44320-02034
19318884 · 94859780
This part cross-references / interchanges with the following part numbers:
19318884, 94859780, 44320-02034
Frequently Asked Questions
Is this 1998-2002 Toyota Corolla power steering pump a direct fit?
Yes. TERREPOWER 930-0105 is a direct-fit power steering pump for the 1998-2002 Toyota Corolla, and it also fits the 2000-2002 Chevrolet Prizm.
Does TERREPOWER 930-0105 come with a pulley or reservoir?
No. The pulley, reservoir, reservoir cap and filter are not included. The box holds one remanufactured pump and an installation kit.
What is the outlet thread size on this power steering pump?
The outlet thread is M16X1.50, with a 16 mm outlet diameter and a banjo bolt attachment. The inlet is a pipe attachment.
How can I tell if this power steering pump is wearing out?
A whine when turning, heavy steering effort or fluid at the pump can be signs of wear. Steering is safety-critical, so have it checked at a shop promptly.
Does 44320-02034 interchange with this power steering pump?
Yes. 44320-02034 is a listed interchange number for TERREPOWER 930-0105.
