Rack and Pinion for 2009-2013 Subaru Forester - TERREPOWER 313-0328

Be the first to review this product
$739.99
WARNING:California Proposition 65▾
MPN: 313-0328
Item Package Quantity: 1
Adding to cart… The item has been added

Have questions?

Ask an Expert
TERREPOWER formerly BBB Industries Rack and Pinion Assembly P/N:313-0328
TERREPOWER formerly BBB Industries Rack and Pinion Assembly P/N:313-0328
$739.99

TERREPOWER 313-0328 rack and pinion for the 2009-2013 Subaru Forester is a remanufactured hydraulic unit that turns steering wheel input into the side-to-side push on the tie rods.

  • Remanufactured hydraulic power steering rack and pinion
  • Inner tie rods included
  • Designed for dependability and reliability throughout the service life of the vehicle
  • 3.188 total turns lock to lock

Heavy or loose steering, a knock when turning, or fluid leaking at the rack can mean the rack and pinion is worn. These signs alone don't prove it is the problem; a worn outer tie rod can also leave steering feeling loose.

It's a direct-fit replacement for the 2009-2013 Subaru Forester.

Specifications

Fit and size

  • Quantity per vehicle: 1
  • Input shaft length: 3.375 in (85.73 mm)
  • Steering input shaft diameter: 0.988 in (25.08 mm)
  • Distance between mounting holes: 3.38 in (85.852 mm), 2 mounting holes
  • End to end length: 49.375 in (1254.13 mm)
  • Pressure port thread size: M14X1.50
  • Return port thread size: M16X1.50
  • Total turns lock to lock: 3.188

Build and materials

  • Type: hydraulic
  • Condition: remanufactured
  • Inner tie rods: included
  • Country of origin: Mexico

In the box

One remanufactured rack and pinion with the inner tie rods. Outer tie rods and bushings are not included. This listing holds one unit, and the vehicle takes one.

Interchange: 34110-SC010 · 34110-SC011 · 34110-SC012

This part cross-references / interchanges with the following part numbers:

34110-SC010, 34110-SC011, 34110-SC012

Frequently Asked Questions

Is this steering rack right for the 2009-2013 Subaru Forester?

Yes. TERREPOWER 313-0328 fits the 2009-2013 Subaru Forester, and the vehicle takes one rack and pinion.

Does this rack and pinion assembly come with tie rods?

The inner tie rods are included. Outer tie rods and bushings are not, so order them separately if yours need replacing.

What thread sizes are the ports on the TERREPOWER 313-0328?

The TERREPOWER 313-0328 has an M14X1.50 pressure port and an M16X1.50 return port.

Does the TERREPOWER 313-0328 replace the 34110-SC010 number?

Yes. TERREPOWER 313-0328 is cross-referenced to 34110-SC010, as well as 34110-SC011 and 34110-SC012.

How many turns lock to lock does this rack and pinion have?

It has 3.188 total turns lock to lock. The input shaft is 25.08 mm (0.988 in) in diameter and 85.73 mm (3.375 in) long.
