Front Right CV Axle Shaft for 2022-2023 Nissan Rogue - TrakMotive NI-86017

$198.99

TrakMotive CV Axle Shaft NI-86017 - view 2

TrakMotive CV Axle Shaft NI-86017 - view 3

Part number: NI-86017

UPC: 840140518054

Condition: New

Weight: 22.50 LBS

Item Package Code: EA

Part Has Core (Y/N): N

Item Package Quantity: 1

$198.99

Current Stock: 22

Quantity:

Adding to cart… The item has been added

Have questions?

Ask an Expert

TrakMotive CV Axle Shaft P/N:NI-86017

$198.99

Description

TrakMotive NI-86017 front right CV axle shaft for the 2022-2023 Nissan Rogue transfers drive torque to the front right wheel while the suspension moves. This TrakMotive CV axle has a joint at each end, so the wheel keeps turning as it steers and the suspension travels.

Long-male inboard joint with 29 splines
Conventional outboard joint with 29 splines
Thermoplastic boots on the inboard and outboard joints
Axle nut included, with M24x1.5 thread, 32 mm hex and stake locking
Overall compressed length of 948 mm (37.31 in)

Quick facts

Part: TrakMotive NI-86017 CV axle shaft
Fits: 2022-2023 Nissan Rogue
Position: Front right
Condition: New

A click when turning, vibration under acceleration or a torn boot can mean the joint is worn. Before you replace this CV axle shaft, rule out a worn wheel bearing or a tire problem, which can make similar noises. This listing is one CV axle shaft for the front right; the front left is a separate part, and both are normally replaced together.

Fits

This CV axle shaft fits the 2022-2023 Nissan Rogue, which takes one on the front right side.

Specifications

Fit and size

Position: front right
Quantity per vehicle: 1
Overall compressed length: 948 mm (37.31 in)
Overall extended length: 1006 mm (39.625 in)
Splines: 29 inboard, 29 outboard
Axle nut: M24x1.5 thread, 32 mm (1.25 in) hex, stake locking

Build and materials

Inboard joint: long-male, spline connection
Outboard joint: conventional, spline connection
Boot material: thermoplastic (inboard and outboard)
ABS tone ring: not included
Condition: new
Warranty: TrakMotive limited lifetime warranty
Country of origin: China

In the box

One CV axle shaft and its axle nut. The ABS tone ring is not included.

Interchange: NCV53214

Manufacturer's description

Product specs

Vehicles it fits

Interchange numbers

This part cross-references / interchanges with the following part numbers:

NCV53214, NI-86017

Buyer's Q&A

Frequently Asked Questions

Does the TrakMotive NI-86017 fit the 2022-2023 Nissan Rogue?

Yes. TrakMotive NI-86017 is the front right CV axle shaft for the 2022-2023 Nissan Rogue, and the Rogue takes one on that side.

Does the TrakMotive CV axle shaft come with the axle nut?

Yes. This front right CV axle shaft includes its axle nut (M24x1.5 thread, 32 mm hex, stake locking); the ABS tone ring is not included.

How long is this front right CV axle shaft?

TrakMotive NI-86017 measures 948 mm (37.31 in) compressed and 1006 mm (39.625 in) extended, with 29 splines at the inboard and outboard ends.

What joints and boots does this front right CV axle shaft have?

It has a long-male inboard joint and a conventional outboard joint, each with 29 splines, and thermoplastic boots on both joints.

Is NCV53214 an interchange for TrakMotive NI-86017?

Yes. NCV53214 is listed as an interchange number for TrakMotive NI-86017, the front right CV axle shaft.
