TrakMotive TO-8166 front right CV axle shaft for the 1984-1985 Toyota 4Runner and other vehicles carries drive torque to the wheel. Two joints let the wheel move with the suspension while the shaft keeps turning.
- 30 splines on both the inboard and outboard ends
- Male outboard joint with one outboard shaft bolt
- Axle bolt with M8x1.25 thread, 46 mm length and 13 mm hex size
- Overall compressed length of 587 mm (23.11 in)
Quick facts
- Part: TrakMotive TO-8166 CV axle shaft
- Fits: 1984-1985 Toyota 4Runner and other vehicles
- Position: Front right
- Condition: New
A worn CV axle shaft can show up as clicking when turning, vibration while accelerating or grease around a torn joint boot. A worn wheel bearing can make similar noise, so these signs alone do not prove the axle is the problem.
Fits
This CV axle shaft for the 1984-1985 Toyota 4Runner also fits the 1981-1987 Toyota Land Cruiser and the 1979-1980 and 1982-1985 Toyota Pickup. This listing is one front right axle shaft, and the 1984-1985 Toyota 4Runner takes one on this side. The front left is a separate part, and both sides are normally replaced together.
Specifications
Fit and size
- Position: Front right
- Quantity per vehicle: 1
- Overall compressed length: 587 mm (23.11 in)
- Inboard splines: 30
- Outboard splines: 30
- Axle bolt: M8x1.25 thread, 46 mm long, 13 mm hex
Build and materials
- Outboard joint type: Male
- ABS tone ring: not included
- Condition: New
- Warranty: TrakMotive limited lifetime warranty
- Country of origin: China
In the box
One front right CV axle shaft. The axle nut is not included, so plan on a new nut rather than reusing the old one.
Interchange: 80-6303 · TO-8-8870 · AX-9331
329166 · NCV69074 · 93700 · 40751032
This part cross-references / interchanges with the following part numbers:
80-6303, 329166, NCV69074, 93700, 40751032, TO-8-8870, TO-8166, AX-9331
Frequently Asked Questions
Is this the right CV axle shaft for the 1984-1985 Toyota 4Runner?
Yes. TrakMotive TO-8166 is a front right CV axle shaft for the 1984-1985 Toyota 4Runner. The left side needs its own axle.
Does this TrakMotive CV axle come with the axle nut?
No. This listing is one front right axle shaft, and the axle nut is not included. Plan on a new nut instead of reusing the old one.
How long is this TrakMotive CV axle shaft?
The TrakMotive TO-8166 has an overall compressed length of 587 mm (23.11 in), with 30 splines at both the inboard and outboard ends.
What can clicking when turning mean on a front right CV axle?
Clicking while turning, vibration when accelerating or grease around a torn joint boot can all point to a worn axle. Have it inspected promptly rather than driving on it.
Does this CV axle shaft include an ABS tone ring?
No. TrakMotive TO-8166 does not include an ABS tone ring.
