Wagner SX2423 front brake pad for the 2022-2025 Ford E-Transit and other vehicles is a semi-metallic pad made for driving with frequent stops and heavy loads.
- SevereDuty line, designed and tested for fleets, police-pursuit vehicles and other demanding conditions
- Carbon-based friction material engineered in-house for long lasting braking performance in the toughest applications
- Rigorous OE-style on-vehicle testing under extreme heat, frequent stopping and heavy loads
- OE style shims, slots and chamfers
- Wagner OE25™ zero-copper friction formulation
Squealing or grinding under braking, pulling to one side or a brake warning light can mean the pads are worn. Before you replace them, rule out a sticking caliper or worn rotors, which can produce similar noise and pulling.
This pad is a direct-fit replacement for the 2021-2025 Ford Transit-150, the 2021-2025 Ford Transit-250 and many other vehicles. The "Vehicles it fits" section shows the other models it fits.
Specifications
Fit and size
- Position: front
- Quantity per vehicle: 1
- Pad wear sensor: electronic, included
Build and materials
- Friction material: semi-metallic, carbon-based
- Formulation: Wagner OE25™ zero copper
- Friction material attachment: integrally molded
- Slotted, with chamfered edges
- Country of origin: Mexico
In the box
This listing is one front disc brake pad set, and a vehicle takes one set. It comes with mounting hardware, abutment clips, pad shims and the electronic pad wear sensor.
Interchange / FMSI:
FMSI: 9648-D2423 · D2423 · D2504
Interchange: 1214-2423-00 · 1214-2423-01 · 1551-2423-00 · 1551-2423-01 · 4000-2423-00 · 4000-2423-01 · SDF2423 · LK4Z2001E · FLD2423 · GMKD2423 · PMD2423H · BRSD2423 · LK4Z2001D · LK4Z2001F · SG9648M · 162423 · 172423 · Z362423 · Z472423
This part cross-references / interchanges with the following part numbers:
SDF2423, LK4Z2001E, FLD2423, GMKD2423, PMD2423H, 1214-2423-00, 1214-2423-01, 1551-2423-00, 1551-2423-01, 4000-2423-00, 4000-2423-01, D2504, BRSD2423, LK4Z2001D, LK4Z2001F, SG9648M, 162423, 172423, Z362423, Z472423, 9648, 9648-D2423, D2423
Frequently Asked Questions
Are these the right brake pads for the 2021-2025 Ford Transit-250?
Yes. Wagner SX2423 is a front brake pad for the 2021-2025 Ford Transit-250. The "Vehicles it fits" section shows the other vehicles it fits.
Do these Wagner SevereDuty pads come with hardware and a wear sensor?
Yes. Wagner SX2423 includes mounting hardware, abutment clips, pad shims and an electronic pad wear sensor. The listing is one front set, and the vehicle takes one.
What friction material do the Wagner SX2423 pads use, and do they contain copper?
They use a semi-metallic, carbon-based friction material in the Wagner OE25™ zero-copper formulation, so they contain no copper. The friction material attachment is integrally molded.
How can I tell my Wagner SevereDuty front pads are worn out?
Squealing, grinding or a brake warning light can mean worn pads. During a brake service, a shop can measure the remaining friction material to see how much is left.
Does Wagner SX2423 replace SDF2423?
Yes. SDF2423 is on the interchange list for Wagner SX2423, along with LK4Z2001E and FLD2423. The full list of numbers is at the bottom of the description.
