Baldwin BF7674-D fuel filter for the 1999-2005 Workhorse P42 V8 6.5L and other vehicles and equipment separates water from the fuel. You may also see this Baldwin Filters fuel filter listed as a fuel water separator filter.
- Secondary fuel/water separator element with a drain
- One grommet attached to the element
Quick facts
- Part: Baldwin BF7674-D fuel filter
- Also called: fuel water separator filter
- Fits: 1999-2005 Workhorse P42 V8 6.5L and other vehicles and equipment
Hard starting, rough running or a loss of power can mean this filter is restricted, though a weak fuel pump or a damaged fuel line can be behind the same signs.
Fits
It is listed for a wide range of Workhorse, Chevrolet and GMC models, including the 1999-2005 Workhorse Custom Chassis P32 V8 6.5L and the 1999-2005 Workhorse Custom Chassis P42 V8 6.5L, with one filter called for in each. The catalog also covers Caterpillar and Perkins engines and John Deere equipment. Open the "Vehicles it fits" section to check your exact model and engine.
Specifications
Fit and size
- Quantity per application: 1
- Outer diameter: 83.3 mm (3 9/32 in)
- Inner diameter: 16.7 mm (21/32 in)
- Height: 151.6 mm (5 31/32 in)
Build and materials
- Type: secondary fuel/water separator element with drain
- Grommet: 1, attached
- Country of origin: United States
Installation notes
- Tabs and keys are not needed for installation.
Interchange: Caterpillar 100-5593 · Caterpillar 138-3098 · Caterpillar 159-6102
GMC 12554082 · John Deere RE52987 · John Deere RE53400 · John Deere RE62419 · John Deere RE509031
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Will the Baldwin BF7674-D fit a 1999-2005 Workhorse Custom Chassis P32 V8 6.5L?
Yes. The Baldwin BF7674-D is listed for the 1999-2005 Workhorse Custom Chassis P32 V8 6.5L, with one filter called for. Open the "Vehicles it fits" section for other models and engines.
What are the outer diameter and height of the Baldwin BF7674-D?
The outer diameter is 83.3 mm (3 9/32 in), the inner diameter is 16.7 mm (21/32 in) and the height is 151.6 mm (5 31/32 in).
Does this fuel filter need a tab or key to install?
No. Tabs and keys are not needed for installation, and one grommet comes attached to the element.
Does the Baldwin BF7674-D replace Caterpillar 100-5593?
Yes. Caterpillar 100-5593 is one of the numbers the Baldwin BF7674-D replaces, along with other Caterpillar, John Deere and GMC numbers.
Could a clogged fuel filter cause hard starting?
Yes, a restricted filter can contribute to hard starting, rough running or a loss of power. Fuel pressure tests are best left to a shop.
