Front Right CV Axle for 2020-2022 Toyota Corolla & More - A1 CARDONE 66-5449

$218.99

Vehicles this part fits

    Part number: 66-5449
    UPC: 884548322332
    Condition: New
    Weight: 19.00 LBS
    Item Package Quantity: 1
    $218.99
    Adding to cart… The item has been added

    Have questions?

    CARDONE New CV Axle Assembly P/N:66-5449
    CARDONE New CV Axle Assembly P/N:66-5449
    $218.99
    $218.99

    A1 CARDONE 66-5449 front right CV axle for the 2020-2022 Toyota Corolla and other vehicles sends drive torque to the front wheel while the suspension and steering move. This A1 CARDONE CV axle, also called a CV axle assembly, comes as a complete axle with CV joints.

    • Neoprene boots with additional bellows where needed, to resist bellow stress and cracking, the leading cause of boot failure
    • Shaft individually verified for straightness, for vibration-free performance at all speeds
    • Boot clamps pneumatically crimped to seal the boot to the housing
    • Joint grease that withstands high-temperature and high-torque demands
    • Precision-rolled splines and threads for fit into the hub, the transmission and the axle nut
    • Transmission seal diameter precision-machined after heat treatment for correct surface finish

    Quick facts

    • Part: A1 CARDONE 66-5449 CV axle
    • Also called: CV axle assembly
    • Fits: the 2020-2022 Toyota Corolla and other vehicles
    • Position: Front right
    • Material: Steel shaft, neoprene boot
    • Condition: New

    Clicking or snapping on tight turns, a thump when accelerating, or grease on the chassis and suspension can mean the axle is worn. Before replacing it, look over the boot and joints with the engine off for tears or leaking grease. The 2020-2022 Toyota Corolla takes one axle on the front right; the front left is a separate part.

    Fits

    It is a front right CV axle replacement for the 2020-2022 Toyota Corolla, and the vehicles it fits include the 2016-2020 Toyota Prius and the 2019-2022 Toyota Prius AWD-e. If your car is none of these, look for its year and model in the "Vehicles it fits" section.

    Specifications

    Fit and size

    • Position: Front right
    • Quantity per vehicle: 1
    • Shaft diameter: 27 mm (1.063 in)
    • Compressed length: 948 mm (37.323 in)
    • Inboard joint: splined, 24 splines
    • Outboard joint: splined, 26 splines
    • Axle nut thread: M22x1.5
    • Axle nut socket size: 30 mm (1.181 in)

    Build and materials

    • Shaft material: steel
    • Boot material: neoprene, 5 ribs
    • Axle nut type: 12-point
    • ABS tone ring: not included
    • Condition: New
    • Country of origin: China

    In the box

    One complete CV axle with a new axle retaining nut and an instruction sheet.

    Installation notes

    • Remove and install one CV axle at a time.
    • Never let the axle hang unsupported, which can damage the inner joint.
    • Tighten the axle nut with a torque wrench to the vehicle maker's specification, never an impact wrench.
    • Install new transaxle seals when replacing the axle.

    Interchange: 4341047040

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    4341047040

    Frequently Asked Questions

    Is this the front right CV axle for the 2020-2022 Toyota Corolla?

    Yes. A1 CARDONE 66-5449 is a front right CV axle for the 2020-2022 Toyota Corolla. The front left axle is a separate part.

    Is this a Prius CV axle for the 2016-2020 Toyota Prius?

    Yes. A1 CARDONE 66-5449 is listed for the 2016-2020 Toyota Prius, and each application takes one axle on this front right side.

    Does this CV axle come with a new axle nut?

    Yes. The A1 CARDONE 66-5449 comes with a new 12-point axle retaining nut, M22x1.5, and an instruction sheet. An ABS tone ring is not included.

    What can clicking when I turn hard mean for a front CV axle?

    A clicking or snapping noise on tight turns, a thump under acceleration or grease on the suspension can mean a worn joint or a split boot.

    Does this A1 CARDONE axle replace part number 4341047040?

    Yes. 4341047040 is listed as an interchange number for A1 CARDONE 66-5449, the front right CV axle.
