A1 CARDONE 6E-6010 fuel injection throttle body for the 2007-2010 Ford F-150 V8 4.6L and other vehicles controls how much air enters the engine. This new electronic throttle body is engineered to match the O.E. design.
- Built and tested as a complete assembly for quick installation
- Housing, throttle plate, position sensors, throttle actuator motor and return spring made to precise dimensions
- Tested for response time and air flow at multiple points
- Throttle position sensor included
- Installs without any modification to the vehicle
Quick facts
- Part: A1 CARDONE 6E-6010 fuel injection throttle body
- Fits: the 2007-2010 Ford F-150 V8 4.6L and other vehicles
- Condition: New
A failing electronic throttle body can show up as a lit check-engine or service-engine light, or as engine speed that falls back toward idle in fail-safe mode. These signs alone do not prove the throttle body is at fault; a vacuum leak can cause similar trouble.
Fits
The vehicles it fits include the 2007-2010 Ford F-150 V8 4.6L, the 2010-2012 Ford Fusion V6 3.5L and the 2007-2010 Ford Edge V6 3.5L. The 2007-2010 Ford F-150 V8 4.6L takes one throttle body. If your vehicle isn't named here, look it up in the "Vehicles it fits" section on this page.
Specifications
Fit and size
- Quantity per vehicle: 1
- Bore diameter: 65 mm (2.559 in)
- Inlet diameter: 80 mm (3.15 in)
- Outlet diameter: 71 mm (2.795 in)
Build and materials
- Throttle body type: Electric
- Terminal type: Blade
- Throttle position sensor: included
- Fuel system type: Gas
- Condition: New
- Country of origin: China
In the box
One electronic throttle body and one instruction sheet. Mounting hardware, a gasket or seal, fuel injectors, an idle air control motor and a throttle body spacer are not included, so plan on new bolts and a new gasket or seal, because the old ones may not be reusable.
Installation notes
- A relearn calibration procedure is necessary after installing the replacement throttle body.
- The instruction sheet that comes with the part covers the steps.
Interchange: 7T4Z9E926FA · 7T4Z9E926FC · 7T4Z9E926EA
This part cross-references / interchanges with the following part numbers:
7T4Z9E926FA, 7T4Z9E926FC, 7T4Z9E926EA
Frequently Asked Questions
Does the A1 CARDONE 6E-6010 throttle body fit the 2010-2012 Ford Fusion V6 3.5L?
Yes, A1 CARDONE 6E-6010 fits the 2010-2012 Ford Fusion V6 3.5L and the 2007-2010 Ford Edge V6 3.5L; for any other vehicle, look it up in the "Vehicles it fits" section.
Are bolts or a gasket included with the A1 CARDONE 6E-6010 throttle body?
No, the box holds one electronic throttle body and an instruction sheet; mounting hardware, a gasket or seal, fuel injectors and an idle air control motor are not included.
What bore size does this electric throttle body have?
This A1 CARDONE 6E-6010 has a 65 mm (2.559 in) bore, an 80 mm (3.15 in) inlet diameter and a 71 mm (2.795 in) outlet diameter.
What happens when an electronic throttle body fails?
The control module turns on the MIL, SES or CEL light and switches to a fail-safe mode. In that mode it gradually brings engine speed down to idle.
Do I have to do anything after installing a replacement electronic throttle body?
Yes, a relearn calibration procedure is necessary after installing the replacement throttle body.
