Delphi FG2506 fuel pump module for the 2017 Chevrolet Express 3500 V8 4.8L, the 2017-2020 Express 3500 V8 6.0L, the 2018-2020 Express 3500 V6 4.3L and other vehicles moves fuel from the tank toward the engine. This Delphi fuel pump module assembly also carries the float arm used for the gas gauge reading.
- Float height and float retention are set for correct gas gauge reading
- Lower amperage draw puts less load on the vehicle's electrical system
- Delphi fuel pump module validated and tested, then matched to its vehicle application
- Design and durability give lower failure rates
Quick facts
- Part: Delphi FG2506 fuel pump module
- Also called: fuel pump assembly
- Fits: 2017 Chevrolet Express 3500 V8 4.8L, the 2017-2020 Express 3500 V8 6.0L, the 2018-2020 Express 3500 V6 4.3L and other vehicles
- Condition: New
Hard starting, sputtering or a gas gauge that reads wrong can mean the pump module is worn, though a clogged fuel filter or a faulty fuel pump relay can also be behind them, so find the cause before you replace anything. Delphi builds its fuel pumps to its OE standards.
Fits
This fuel pump module also fits the 2017 GMC Savana 3500 V8 4.8L, the 2017-2020 Savana 3500 V8 6.0L, the 2018-2020 Savana 3500 V6 4.3L and the 2017-2020 Chevrolet Express 4500. The 2017-2020 Chevrolet Express 4500 takes one module. If your van is not named here, look it up by year and engine in the "Vehicles it fits" section.
Specifications
- Quantity per vehicle: 1
- Float arm: included
- Seal: included
- Condition: New
- Country of origin: Thailand
In the box
One fuel pump module with its float arm, seal and instruction sheet.
Installation notes
- Check and clean the fuel tank before installing the module.
- The instruction sheet in the box covers the steps.
Interchange: EFG2506 · 19353008 · 84177558 · 84177564 · 84478128 · 84607909 · 86786772
This part cross-references / interchanges with the following part numbers:
EFG2506, 19353008, 84177558, 84177564, 84478128, 84607909, 86786772
Frequently Asked Questions
Does the Delphi FG2506 fuel module fit the 2017 Chevrolet Express 3500 V8 4.8L?
Yes. Delphi FG2506 fits the 2017 Chevrolet Express 3500 V8 4.8L, which takes one module. Other vans are matched by year and engine in the "Vehicles it fits" section.
Does this fuel pump assembly come with the float arm?
Yes. Delphi FG2506 comes with the float arm, a seal and an instruction sheet.
What does the lower amperage of this Delphi module mean for the electrical system?
The module draws less amperage, so it puts less load on the vehicle's electrical system.
Will the float arm on this fuel pump module give a correct gas gauge reading?
Yes. Its empty float height and float retention match OE specifications, which gives a correct gas gauge reading.
Should the fuel tank be cleaned before installing this fuel pump module?
Yes. Check and clean the fuel tank before you install the module. The instruction sheet in the box covers the installation steps.
