Get smooth, quiet rear braking back on your late-model Ford truck with the Raybestos Specialty Truck Coated Disc Brake Rotor 682747. This rear disc brake rotor drops in as a direct-fit replacement for the 2021-2024 Ford F-150, 2022-2023 Ford Expedition, 2022-2023 Lincoln Navigator, and 2023-2024 Ford F-150 Lightning (All engines), matching the original rotor's OE fit, form, and function.
- OE fit, form, and function: a vehicle-specific design built to match the original rotor's fit, form, and function.
- Vented with cooling vanes: a vented, full cast-iron rotor with cooling vanes matched to the OE design to help dissipate heat and reduce fade and noise.
- Turned, non-directional finish: a smooth turned braking surface gives the pads solid engagement for an effective stop right out of the box.
- Rust-resistant coating: finished with a protective coating for corrosion resistance; follows SAE standards for tensile strength, hardness, and iron grade.
Specs: 13.2 in (336 mm) outside diameter, 6 stud/lug holes, nominal thickness 20 mm (0.8 in) with a discard thickness of 18.5 mm (0.7 in). Does not include an ABS tone ring or wheel bearings. Sold individually; each listed application uses two, so order two and replace both rear rotors as a matched pair for even, balanced braking. Country of origin: China.
Interchange: YH720512 · YH720512P · 75079DG · 75079DL · 75079SD · 682747RGS · 120.65167 · 121.65167 · BR901898 · BR901898-01 · BR90189801 · BR901898-02 · BR90189802 · ML1Z2C026C · ML3Z2C026B · ML3Z2C026D · ML3Z2CO26B · BRRF431 · TN682747GEO · 1427-732837 · 1427732837 · 6672507. Manufacturer part number 682747.
This part cross-references / interchanges with the following part numbers:
YH720512, YH720512P, 75079DG, 75079DL, 75079SD, 682747RGS, 120.65167, 121.65167, BR901898, BR901898-01, BR901898-02, ML1Z2C026C, ML3Z2C026B, ML3Z2C026D, ML3Z2CO26B, BRRF431, TN682747GEO, 1427-732837, 6672507
Frequently Asked Questions
What vehicles does rotor 682747 fit?
It's a direct-fit replacement for the 2021-2024 Ford F-150, 2022-2023 Ford Expedition, 2022-2023 Lincoln Navigator, and 2023-2024 Ford F-150 Lightning (All engines). Check the "Vehicles it fits" section to confirm fitment.
Is this a front or rear rotor?
This is a rear disc brake rotor, as listed in the catalog for the covered applications.
How many rotors do I need?
It's sold individually. Each listed application uses two, so order two to replace both rear rotors as a matched pair for even, balanced braking.
Is this a vented rotor?
Yes. It's a vented, full cast-iron rotor with cooling vanes matched to the OE design to help dissipate heat and reduce brake fade.
Does it include an ABS tone ring or wheel bearings?
No. An ABS tone ring is not included, and wheel bearings are not included either—reuse or source those separately as directed by the service procedure.
