Dorman 90-161 rear right leaf spring for the 1995-1997 Toyota Tacoma holds the weight and payload of the vehicle at that corner. Also called a leaf spring assembly, this Dorman leaf spring replaces springs damaged by overloading, collision, cracking or corrosion.
- Steel construction with 3 leaves and a 1.181 inch pack thickness
- Load rate of 1490 pounds
- Up-turned eye at both ends, with bushings included
- Standard-grade replacement that needs no axle modification
Quick facts
- Part: Dorman 90-161 leaf spring
- Also called: leaf spring assembly
- Fits: 1995-1997 Toyota Tacoma
- Position: Rear right
- Material: Steel
- Condition: New
A rear end that sags or sits low under load, a cracked or broken leaf, heavy rust or a flattened spring can mean this spring is worn, though worn rear shocks or a damaged shackle can be behind some of those signs too. Find the cause before replacing it.
Fits
It is a direct replacement for the 1995-1997 Toyota Tacoma, built to fit and work like the original spring. This listing is one spring for the rear right, and that axle's other side is a separate part normally replaced at the same time. The 1995-1997 Toyota Tacoma takes one spring per side.
Specifications
Fit and size
- Position: Rear right
- Quantity per side: 1
- Leaf quantity: 3
- Leaf width: 2.375 inches
- Pack thickness: 1.181 inches
- Arch length: 5 inches
- Length axis 1 and axis 2: 22.5 inches each
- Length B: 28.625 inches
- Load rate: 1490 pounds
Build and materials
- Material: Steel
- End attachment: up-turned eye at both ends
- Bushings: included, black
- Mounting hardware: not included
- Grade: standard replacement
- Axle modification: not needed
- Condition: New
In the box
One leaf spring with its bushings. Mounting hardware is not included, so plan on new bolts and hardware, since the old ones may not be reusable.
Interchange: 90-161DAY
4821004032
Frequently Asked Questions
Does this 1995-1997 Tacoma leaf spring fit the rear right side?
Yes. Dorman 90-161 is a rear right leaf spring for the 1995-1997 Toyota Tacoma. The rear left is a separate part.
Are these 1995-1997 Toyota Tacoma rear leaf springs the same on the left and right?
No. This listing is the rear right spring only, and the rear left spring is ordered separately.
What is the load rate of this rear right leaf spring?
The load rate is 1490 pounds. The spring has 3 leaves, a 1.181 inch pack thickness and a 2.375 inch leaf width.
Does the Dorman 90-161 come with bushings and mounting hardware?
Bushings are included, but mounting hardware is not. The listing is one leaf spring, so plan on new bolts and hardware.
Does this leaf spring need any axle modification?
No. This standard-grade replacement spring needs no axle modification, and it has an up-turned eye at each end.
