Remanufactured Front Right Brake Caliper for 2001-2010 Chrysler PT Cruiser - Raybestos FRC11102

$107.99
WARNING:California Proposition 65▾

Vehicles this part fits

    Part number: FRC11102
    UPC: 753497956120
    Condition: Refurbished
    Weight: 9.53 LBS
    Item Package Quantity: 1
    $107.99
    Adding to cart… The item has been added

    Have questions?

    Raybestos Brakes Disc Brake Caliper P/N:FRC11102
    Raybestos Brakes Disc Brake Caliper P/N:FRC11102
    $107.99
    $107.99

    Raybestos Brakes FRC11102 front right brake caliper for the 2001-2010 Chrysler PT Cruiser clamps the brake pads against the rotor to slow the wheel. This remanufactured, semi-loaded disc brake caliper includes its bracket, and its materials match OE specifications.

    • Raybestos R-Line non-plated caliper; castings, guide pins and brackets are inspected before reuse
    • New seals, boots, bleeder screws, abutment hardware, banjo bolts and O-rings for leak-free operation
    • EPDM70 rubber components for heat resistance and durability
    • Each caliper is 100% pressure tested

    Quick facts

    • Part: Raybestos Brakes FRC11102 brake caliper
    • Also called: disc brake caliper
    • Fits: 2001-2010 Chrysler PT Cruiser
    • Position: Front right
    • Material: Cast iron
    • Condition: Remanufactured

    A caliper that sticks, leaks fluid around the piston boot, or wears one pad faster than the other can be due for replacement, and a pull to one side under braking is another sign. Before you replace it, rule out worn pads, a damaged brake hose and a warped rotor, since each of those can pull the car to one side too.

    Fits

    It is a direct-fit replacement caliper for the 2001-2010 Chrysler PT Cruiser. The front axle has one caliper on each side; this listing is the front right one, the front left is ordered separately, and the two are normally replaced together.

    Specifications

    Fit and size

    • Position: Front right
    • Sold individually: 1 caliper
    • Caliper type: Floating
    • Piston diameter: 57.150 mm (2.250 in)
    • Piston quantity: 1
    • Bleeder screw thread: M10X1.00
    • Bracket mounting hole: 12 mm, thread pitch 1.75 mm
    • Casting number: 134469

    Build and materials

    • Condition: Remanufactured
    • Caliper configuration: Friction Ready, semi-loaded
    • Caliper casting material: Cast iron
    • Surface finish: Coated
    • Bracket surface finish: Coated
    • Mounting bracket: included
    • Country of origin: Mexico

    In the box

    One remanufactured caliper with its mounting bracket.

    Interchange: 15-11145 · 99-17664B · 18-B4781 · 18-B4781A · 18-P4781 · 141.63009 · 142.63009 · 14-1145
    5189295AA · SC0284 · SC0292

    Product information is for general reference and may contain errors. See our Disclaimer.

    This part cross-references / interchanges with the following part numbers:

    15-11145, 99-17664B, 18-B4781, 18-B4781A, 18-P4781, 141.63009, 142.63009, 5189295AA, SC0284, SC0292, 14-1145

    Frequently Asked Questions

    Is Raybestos Brakes FRC11102 a front brake caliper for the 2001-2010 Chrysler PT Cruiser?

    Yes. Raybestos Brakes FRC11102 is the front right caliper for the 2001-2010 Chrysler PT Cruiser. The front left caliper is a separate part.

    Does this remanufactured caliper come with its mounting bracket?

    Yes. It is a semi-loaded caliper and bracket assembly, so the mounting bracket is included with the caliper.

    What piston size and bleeder screw thread does this caliper have?

    This Raybestos Brakes FRC11102 floating caliper has one 57.150 mm (2.250 in) piston and an M10X1.00 bleeder screw thread.

    What gets replaced when a Raybestos R-Line caliper is remanufactured?

    Seals, boots, bleeder screws, abutment hardware, banjo bolts and O-rings are replaced with new parts. Castings, guide pins and brackets are inspected before they are reused.

    What does a leaking or sticking front right caliper look like?

    Fluid around the piston boot, a pull to one side under braking, or one pad worn faster than the other can point to the caliper. A shop can test it; have suspect brakes checked promptly.
