CVT Belt for 2000-2002 Kawasaki KAF950 Mule 2510 Diesel - Gates 28R4313

$193.99

Gates Automatic Continuously Variable Transmission (CVT) Belt 28R4313

Part number: 28R4313

UPC: 770075815815

Condition: New

Weight: 1.17 LBS

Item Package Quantity: 1

$193.99

Current Stock: 76

Quantity:

Adding to cart… The item has been added

Have questions?

Ask an Expert

Gates Automatic Continuously Variable Transmission (CVT) Belt P/N:28R4313

$193.99

Description

Gates 28R4313 CVT belt for the 2000-2002 Kawasaki KAF950 Mule 2510 Diesel carries drive power through the continuously variable transmission. It belongs to the G-Force RedLine series, built for demanding off-road duty.

G-Force RedLine series, the first of a new generation of Gates CVT belts
Design aimed at acceleration and top speed with low speed-ratio and energy loss in extreme off-road use
Crack- and wear-resistant construction for the most demanding applications
Greater heat resistance and recovery under severe duty cycles
Patented compound optimized for axial stiffness, so the belt runs at higher continuous torques or loads
Tested under extreme conditions in controlled environments and on race vehicles

Quick facts

Part: Gates 28R4313 CVT belt
Also called: cvt transmission belt
Fits: 2000-2002 Kawasaki KAF950 Mule 2510 Diesel
Position: Drive belt
Material: EPDM
Condition: New

A worn cvt transmission belt can show cracks, fraying or a glazed surface, and the machine can slip or pull weakly under load. Before you replace the belt, rule out the clutches and sheaves, since slipping can start there too.

Fits

This belt fits the 2000-2002 Kawasaki KAF950 Mule 2510 Diesel, and that machine takes one.

Specifications

Fit and size

Position: Drive belt
Quantity per vehicle: 1
Top width: 32 mm (1.277 in)
Outside circumference: 1124 mm (44.25 in)
Pitch length: 1095 mm (43.126 in)
Pitch width: 30.3 mm (1.193 in)
Thickness: 15.9 mm (0.627 in)
Cross section designation: RVS-R
Angle: 28

Build and materials

Type: Power sport specialty high performance CVT belt
Construction: Double notched
Belt material: EPDM
Cord material: Aramid
Grade: OE Improved
Condition: New
Country of origin: United States

Interchange: 59011-0012 · 59011-1078 · 59011-1086
28G4313 · XTX2258 · 28C4313

Manufacturer's description

Product specs

Vehicles it fits

Interchange numbers

This part cross-references / interchanges with the following part numbers:

28G4313, XTX2258, 59011-0012, 59011-1078, 59011-1086, 28C4313, 28R4313

Buyer's Q&A

Frequently Asked Questions

Is the Gates 28R4313 CVT belt right for the 2000-2002 Kawasaki KAF950 Mule 2510 Diesel?

Yes, Gates 28R4313 is listed for the 2000-2002 Kawasaki KAF950 Mule 2510 Diesel, which takes one belt. It is a drive belt for that machine's continuously variable transmission.

What size is the Gates 28R4313 belt?

Gates 28R4313 has a 32 mm top width, a 1124 mm outside circumference and a 15.9 mm thickness. Its pitch length is 1095 mm and its pitch width is 30.3 mm.

What is this CVT belt made of?

The belt material is EPDM and the cord material is aramid. The construction is double notched.

What does a worn G-Force RedLine belt look like?

With the engine off and cool, look for cracks, fraying or a glazed surface. In use, slipping or weak pull under load can be signs of wear.

Is 59011-1078 the same belt as Gates 28R4313?

Yes, 59011-1078 is an interchange number for Gates 28R4313, along with 59011-0012 and 59011-1086. The other numbers are on the Interchange line.
