Gates 24244 radiator coolant hose for the 2004-2016 Volvo VNL 6-cylinder 14.9L, the 2014 VNL 6-cylinder 11.9L, the 2016-2017 VNL 6-cylinder 11.9L and other vehicles and equipment carries coolant through the engine's cooling system. It is a straight, unmolded length that you cut to suit the run.
- Green Stripe straight hose for demanding heavy-duty coolant and air use
- Two-ply bias fabric construction for flexibility and strength
- EPDM tube and cover resist cold water leaks and stay soft and pliable under adverse operating conditions
- Compounds engineered to resist electrochemical degradation
- Temperature range of -40 °F to +257 °F (-40 °C to +125 °C)
Quick facts
- Part: Gates 24244 radiator coolant hose
- Fits: the 2004-2016 Volvo VNL 6-cylinder 14.9L, the 2014 VNL 6-cylinder 11.9L, the 2016-2017 VNL 6-cylinder 11.9L and other vehicles and equipment
- Material: EPDM
- Condition: New
Cracks, a soft or swollen cover, or coolant weeping at the ends can mean a coolant hose is wearing out. A low coolant level can have other sources, so with the engine off and cool, look over the whole hose and both ends for cracks, softness or wet spots before you replace it.
Fits
Gates 24244 is listed for a wide range of models from Volvo, GMC, International, Freightliner and other makes, including the 2024 Volvo VNR 6-cylinder 8.9L and the 2020 Volvo VNL 300. The 2024 Volvo VNR 6-cylinder 8.9L takes one.
Specifications
Fit and size
- Centerline length: 36 in (914 mm)
- Inside diameter, both ends: 2.75 in (70 mm)
- Working pressure: 60 psi
- Quantity per vehicle: varies by application
Build and materials
- Material: EPDM
- Construction: 2-ply, straight, not molded
- Standard: exceeds SAE 20R1 Type EC (Class D-1 tube and cover, standard wall)
- Marine: approved for marine applications
- Condition: New
- Country of origin: Mexico
Installation notes
- Cover is marked in 1 in. increments for approximate cut lengths, which allows custom-fit installations.
- For a maintenance-free connection, use PowerGrip SB clamps.
- Not for fuel or oil transfer applications.
Interchange: 31066 · 77275 · 77275GL · 8120 · 57244 · 641 · GPC275 · 21000024 · 21130534 · 21269554 · 21558475 · 22835303 · 8071220 · 8087307
This part cross-references / interchanges with the following part numbers:
31066, 24244, 77275, 77275GL, 8120, 57244, 641, GPC275, 21000024, 21130534, 21269554, 21558475, 22835303, 8071220, 8087307
Frequently Asked Questions
Does the Gates 24244 coolant hose fit the 2024 Volvo VNR 6-cylinder 8.9L?
Yes, Gates 24244 is listed for the 2024 Volvo VNR 6-cylinder 8.9L, which takes one. If your truck or machine is not named here, look it up in the "Vehicles it fits" section.
What inside diameter and length does the Gates 24244 hose have?
Gates 24244 has a 2.75 in. (70 mm) inside diameter at both ends and a centerline length of 36 in. (914 mm).
Can this coolant hose be used for fuel or oil lines?
No. This hose is made for coolant and air applications and is not for fuel or oil transfer.
How hot can this EPDM coolant hose get?
The rated temperature range runs from -40 °F to +257 °F (-40 °C to +125 °C), with a working pressure of 60 psi.
Is this straight coolant hose marked for cutting to length?
Yes. The cover is marked in 1 in. increments to help with approximate cut lengths. For a maintenance-free connection, use PowerGrip SB clamps.
