Gates TCKWP307N timing belt kit with water pump for the 2000-2005 Subaru Outback H4 2.5L and other vehicles replaces the timing belt and water pump together. This Gates timing belt and water pump kit lets you change the belt-driven pump at the same time as the belt.
- PowerGrip Premium timing component kit with a water pump included
- HSN belt with fiberglass cord and 223 curvilinear (II) teeth
- Water pump designed and built for efficient, long-lasting cooling
- Hydraulic tensioner and three idlers packed with the belt
Quick facts
- Part: Gates TCKWP307N timing belt kit with water pump
- Also called: engine timing belt kit with water pump
- Fits: 2000-2005 Subaru Outback H4 2.5L and other vehicles
- Material: HSN, fiberglass cord (belt)
- Condition: New
A squeal or rattle from the front of the engine, or coolant seeping at the water pump, can mean the kit is due. These signs alone do not prove the belt or pump is at fault; a loose accessory belt, for example, can make a similar noise. The engine takes one kit.
Fits
It is a timing belt kit with water pump for the 2000-2005 Subaru Legacy H4 2.5L and also fits the 2000-2005 Subaru Outback H4 2.5L and the 2003-2006 Subaru Baja H4 2.5L.
Specifications
Fit and size
- Quantity per vehicle: 1
- Timing belt width: 27 mm (1.063 in)
- Timing belt teeth: 223
- Idlers: 3
- Water pumps: 1
Build and materials
- Tensioner type: hydraulic
- Belt material: HSN, fiberglass cord
- Tooth type: Curvilinear (II)
- Grade type: OE Exact
- Timing marks: Yes
- Condition: New
- Gates warranty: matches the original manufacturer's timing belt replacement intervals, covering parts, labor and other associated costs
- Country of origin: Japan
In the box
One timing belt, one hydraulic tensioner, three idlers, one water pump, an installation tool, Loctite, a metal gasket, an O-ring and an instruction sheet. Bolts and springs are not included; plan on new bolts, since the old ones may not be reusable.
Installation notes
- Detailed installation instructions come with the kit (instruction sheet 0098-1683).
- Technical Service Bulletins for troublesome applications are included.
Interchange: 24540KN
Frequently Asked Questions
Does Gates TCKWP307N fit the 2003-2006 Subaru Baja H4 2.5L?
Yes. Gates TCKWP307N is listed for the 2003-2006 Subaru Baja H4 2.5L, and that engine takes one kit.
Does the Gates engine timing belt kit with water pump come with a hydraulic tensioner?
Yes. Gates TCKWP307N includes one hydraulic tensioner, three idlers and the water pump. Bolts and springs are not included.
What belt is in this timing belt kit with water pump?
The belt is made of HSN with a fiberglass cord. It is 27 mm (1.063 in) wide and has 223 curvilinear (II) teeth.
How do I tell if the water pump in this kit needs replacing?
A coolant leak at the pump, or a squeal or rumble from the front of the engine, can point that way. With the engine off and cool, look for coolant residue around the pump; a shop can test the cooling system.
Are installation instructions included with this timing belt kit with water pump?
Yes. The kit comes with detailed installation instructions (sheet 0098-1683), Technical Service Bulletins for troublesome applications and an installation tool.
