Monroe Shocks & Struts 173045 front right strut assembly for the 2015-2016 Honda CR-V replaces the strut, coil spring and upper mount as one unit. This complete strut and coil spring assembly has a vehicle-specific design that is fit checked and ride tested.
- Quick-Strut assembly with the strut, coil spring, upper strut mount and insulators preassembled
- Application-specific coil spring engineered to restore ride height and support the vehicle's weight
- Gas-charged passive strut that helps reduce body sway, vibration and road harshness
- Upper strut mount helps keep steering precise and limits noise, vibration, harshness and memory steer
- Protective coating resists rust and corrosion, and salt spray testing backs it up
Quick facts
- Part: Monroe Shocks & Struts 173045 strut assembly
- Also called: complete strut and coil spring assembly
- Fits: 2015-2016 Honda CR-V
- Position: Front right
- Condition: New
A worn front strut can show up as a bouncy ride, nose-dive under braking or a clunk over bumps. Before you replace this one, rule out worn tires and a loose or worn sway bar link, since those can change the ride and add noise too.
Fits
This strut assembly is a direct-fit replacement for the 2015-2016 Honda CR-V.
Specifications
Fit and size
- Position: front right
- Quantity per vehicle: 1 for this side
- Compressed length: 12.49 in (317.2 mm)
- Extended length: 18.94 in (481.1 mm)
- Travel length: 6.45 in
- Body length: 15.13 in
Build and materials
- Type: gas charged, passive suspension
- Finish: protective rust-resistant coating
- Condition: new
- Warranty: Monroe limited lifetime warranty
- Country of origin: China
In the box
One front right strut assembly with coil spring, strut mount, spring and mount insulators and mounting hardware. This listing is sold individually: the front right of the 2015-2016 Honda CR-V takes one, the front left is a separate part ordered on its own, and the two sides are normally replaced together.
Installation notes
- Comes fully assembled, so no spring compressor is needed.
- Strut, spring and mount are replaced together in one step.
Interchange: LS5392041R · 34HN1179
This part cross-references / interchanges with the following part numbers:
LS5392041R, 34HN1179, 173045
Frequently Asked Questions
Are these the right suspension struts for the front right of a 2015-2016 Honda CR-V?
Yes. Monroe Shocks & Struts 173045 is the front right strut assembly for the 2015-2016 Honda CR-V. The front left side is a separate part.
Does the Monroe Quick-Strut 173045 come with the coil spring and strut mount?
Yes. Monroe Shocks & Struts 173045 includes the coil spring, strut mount, spring and mount insulators and mounting hardware in one assembled unit.
How long is the Monroe 173045 strut when compressed and extended?
The Monroe 173045 measures 12.49 in (317.2 mm) compressed and 18.94 in (481.1 mm) extended, with 6.45 in of travel.
What are the signs a gas-charged strut assembly is wearing out?
Oil film on the strut body, uneven tire wear or excess body sway can mean a strut is worn. A shop can confirm it.
Do I need a spring compressor to install this Quick-Strut?
No. The strut, coil spring and mount come fully assembled in this Monroe unit, so no spring compressor is needed.
