Monroe Shocks & Struts 73049 front right suspension strut for the 2011-2014 Toyota Sienna damps front suspension movement and filters out noise, vibration and harshness. It is designed to restore the vehicle's original drivability and performance.
- Monroe OESpectrum line, designed with the right technology for each application
- Twin Technology Active Control System isolates impact-related noise, vibration and harshness
- Rod displaced valving, tuned to each vehicle, adjusts to road extremes (on most applications)
- All-weather fluid with special additives to assist in extreme temperatures and help reduce oil breakdown
- PTFE-banded piston seals consistently between the piston and the pressure tube
- Nitrogen gas charge keeps the tire in contact with the road by reducing aeration (on most applications)
Quick facts
- Part: Monroe Shocks & Struts 73049 suspension strut
- Fits: 2011-2014 Toyota Sienna
- Position: Front right
- Condition: New
A worn strut can show up as a bouncy or floaty ride, a knock over bumps, or oil running down the strut body. These signs alone do not prove the strut is at fault, since worn tires can cause a similar ride complaint.
Fits
This front right strut is a direct-fit replacement for the 2011-2014 Toyota Sienna, which takes one on this side. This listing is one strut; the front left is a separate part, and the pair on that axle is normally replaced at the same time.
Specifications
Fit and size
- Position: front right
- Quantity per vehicle: 1
- Body diameter: 50.4 mm (1.984 in)
- Body length: 16.578 in
- Compressed length: 414.5 mm (16.318 in)
- Extended length: 604.5 mm (23.799 in)
- Travel length: 7.481 in
- Upper mount code: 190
Build and materials
- Construction: gas charged, passive
- Internal rebound bumper: yes
- Adjustment: compression, rebound and ride height not adjustable
- Condition: new
- Warranty: Monroe Limited Lifetime Warranty
- Country of origin: China
In the box
One front right suspension strut with mounting hardware. The strut mount, coil spring and dust shield are not included.
Interchange: 333491R · 339294 · 4851009Z90 · 485108Z002
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
333491R, 339294, 73049, 4851009Z90, 485108Z002
Frequently Asked Questions
Does the Monroe 73049 front right strut fit the 2011-2014 Toyota Sienna?
Yes. Monroe Shocks & Struts 73049 is the front right suspension strut for the 2011-2014 Toyota Sienna. The front left side is a separate part.
Does the Monroe 73049 strut come with mounting hardware?
Yes, Monroe 73049 comes with mounting hardware. The strut mount, coil spring and dust shield are not included.
What are the compressed and extended lengths of this strut?
Compressed length is 414.5 mm (16.318 in) and extended length is 604.5 mm (23.799 in), which gives 7.481 in of travel.
Is oil on the body a sign this front right strut is worn?
It can be. Oil running down the strut body, a bouncy ride or a knock over bumps can mean a worn strut. Look with the engine off and cool; a shop can confirm the cause.
Does the Monroe OESpectrum strut have a warranty?
Yes. Monroe backs this strut with its Limited Lifetime Warranty.
