Distributor for 1975-1976 Ford F-150 & More - MSD 85951

MSD 85951 distributor for the 1975-1976 Ford F-150 V8 6.4L and other vehicles routes spark to the cylinders and comes ready to run. The MSD Ignition distributor has a steel gear installed for hydraulic roller cams, so a Ford FE build with that cam needs no pressed-fit gear swap.

• Steel gear installed, ready for hydraulic roller cams
• CNC machined billet aluminum housing and billet aluminum base
• QPQ coated shaft guided by a sealed ball bearing
• Advance plate and weights fine blanked from chrome moly steel, with weight pins staked and TIG welded to the plate
• Nylon pads for smooth operation of the advance weights
• Stable trigger signals throughout the RPM range

Quick facts

• Part: MSD 85951 distributor
• Fits: 1975-1976 Ford F-150 V8 6.4L and other vehicles
• Condition: New

A worn distributor can show up as hard starting, a misfire or uneven timing. Those signs alone do not prove the distributor is at fault, since a tired spark plug wire can produce a misfire too. If the distributor is the cause, this one replaces it.

Fits

This ready-to-run distributor for Ford FE engines fits the 1975-1976 Ford F-150 V8 6.4L, the 1958-1959 Ford F-250 V8 5.8L, the 1960-1963 F-250 V8 5.4L, the 1964-1966 F-250 V8 5.9L, the 1965-1967 F-250 V8 5.8L, the 1968-1976 F-250 V8 6.4L, the 1967-1969 Ford Mustang V8 6.4L and the 1967-1970 Mustang V8 7.0L, and each takes one. If your Ford is not named here, look it up in the "Vehicles it fits" section.

Specifications

In the box

One distributor with its cap, plus the supplied springs and stop bushings.

Installation notes

• The advance is easy to adjust.
• The assembly can be locked out for crank trigger systems.
