Sealed 1011P 80 piston set for the 1954-1964 Ford F-250 6-cylinder 3.6L and other vehicles replaces the pistons in an engine rebuild. This engine piston set is oversize and gives the performance and dependability of original equipment pistons.
- Sealed Power Vintage line for restoring classic engines
- Cast aluminum pistons made from FM132 eutectic proprietary alloy
- Controlled casting and machining for reliability, durability and long life
- Up-tilt ring grooves improve the seal between piston and ring
- Helps control blow-by
Quick facts
- Part: Sealed 1011P 80 piston set
- Also called: engine piston set
- Fits: 1954-1964 Ford F-250 6-cylinder 3.6L and other vehicles
- Material: Cast aluminum
- Condition: New
Worn pistons can show up as blue exhaust smoke, oil use or lost compression. Worn rings or scored cylinder walls can bring on these symptoms too, so have a shop measure the bores before you buy pistons.
Fits
It is listed for a wide range of Ford, Edsel and Mercury models, led by the 1954-1964 Ford F-250 6-cylinder 3.6L, the 1964 Ford Custom 6-cylinder 3.6L, and the 1959-1964 Ford Galaxie 6-cylinder 3.6L along with the 1960 Galaxie 6-cylinder 3.7L. The fitment calls for six pistons per engine. If your car is not named here, find it in the "Vehicles it fits" section and match its years and engine.
Specifications
Fit and size
- Quantity per vehicle: 6
- Bore diameter: 3.6250 in
- Oversize amount: 0.080 in
- Compression height: 1.858 in
- Piston pin outside diameter: 0.9122 in
- Pin offset: 0.062 in
- Top and second compression ring thickness: 0.09375 in
- Oil ring thickness: 0.1875 in
Build and materials
- Piston material: Cast aluminum
- Piston head type: Flat
- Condition: New
- Country of origin: United States
In the box
The cast piston set. Assembly lubricant is not included.
Frequently Asked Questions
Does the Sealed 1011P 80 piston set fit the 1954-1964 Ford F-250 6-cylinder 3.6L?
Yes. Sealed 1011P 80 is listed for the 1954-1964 Ford F-250 6-cylinder 3.6L, and the fitment calls for six pistons per engine.
Will these pistons work in the 1959-1964 Ford Galaxie 6-cylinder 3.6L?
Yes. Sealed 1011P 80 is also listed for the 1959-1964 Ford Galaxie 6-cylinder 3.6L and the 1960 Galaxie 6-cylinder 3.7L.
How oversize is this Sealed piston set?
The set is 0.080 inch oversize, and its listed bore diameter is 3.6250 inch. Compression height is 1.858 inches.
What material are these flat-head pistons made of?
They are cast aluminum with a flat head, cast from FM132 eutectic proprietary alloy.
Does the 1011P 80 set come with assembly lubricant?
No. Assembly lubricant is not included with Sealed 1011P 80, so you would need to buy it separately.
