Sealed H1561CPA .75MM piston set for the 2013-2018 Ram 1500 V6 3.6L and other vehicles supplies the pistons for an engine rebuild. The engine piston set is built for the performance and dependability of original equipment pistons.
- Flat top anodized hypereutectic coated piston
- Skirt coated with a blend of graphite, teflon and molybdenum
- Blended skirt coat is meant to reduce engine wear, fatigue and piston slap, and to help increase horsepower and fuel efficiency
- Oversized by 0.75 mm
Quick facts
- Part: Sealed H1561CPA .75MM piston set
- Also called: engine piston set
- Fits: 2013-2018 Ram 1500 V6 3.6L and other vehicles
- Material: Hypereutectic
- Condition: New
A knock from the engine, oil burning or a loss of power can mean worn pistons or cylinders. Rings, valves or fuel delivery can produce similar symptoms, so with the engine off and cool, look the engine over for leaks and check for low oil first, and leave compression testing to a shop.
Fits
The set is listed for a wide range of Chrysler, Dodge, Jeep, Ram and Volkswagen models, including the 2011-2017 Jeep Grand Cherokee V6 3.6L and the 2012-2017 Jeep Wrangler V6 3.6L. The 2013-2018 Ram 1500 V6 3.6L takes six pistons.
Specifications
Fit and size
- Oversize amount: 0.75 mm
- Piston head type: Flat
- Piston pin outside diameter: 0.9430 in
- Compression height: 1.328 in
- Top compression ring thickness: 1.50 mm
- Second compression ring thickness: 1.50 mm
- Quantity per vehicle: 6
Build and materials
- Piston material: Hypereutectic
- Skirt coating: graphite, teflon and molybdenum blend
- Grade: Premium
- Condition: New
- Country of origin: India
In the box
Cast pistons, pins and clips. Assembly lubricant is not included.
Interchange: P1169.30 · P1117(6).75 · 224-3855-0.75MM
224388875MM · 3530HCA75MM
Product information is for general reference and may contain errors. See our Disclaimer.
This part cross-references / interchanges with the following part numbers:
224388875MM, P1169.30, P1117(6).75, 224-3855-0.75MM, 3530HCA75MM
Frequently Asked Questions
Is the Sealed H1561CPA .75MM piston set listed for the 2011-2017 Jeep Grand Cherokee V6 3.6L?
Yes. Sealed H1561CPA .75MM is listed for the 2011-2017 Jeep Grand Cherokee V6 3.6L. For another model, look up your own car in the Vehicles it fits section on the product page.
Do these Sealed pistons come with pins and clips?
Yes. The box holds cast pistons, pins and clips. Assembly lubricant is not included.
What is the piston pin diameter on the Sealed H1561CPA .75MM?
On Sealed H1561CPA .75MM the piston pin outside diameter is 0.9430 in and the compression height is 1.328 in. Both top and second compression ring thickness are 1.50 mm.
What coating is on the skirt of these flat-top pistons?
The skirt has a coating that blends graphite, teflon and molybdenum. It is intended to reduce engine wear and piston slap.
Is 224-3855-0.75MM an interchange number for the Sealed H1561CPA .75MM piston set?
Yes. 224-3855-0.75MM is listed as an interchange number for Sealed H1561CPA .75MM, along with P1169.30 and P1117(6).75.
