Engine Piston for 1999-2003 Chevrolet Silverado 2500 & More - Sealed H857CP

$485.99
Sealed Power Engine Piston Set H857CP
Sealed Power Engine Piston Set H857CP

Vehicles this part fits
    Part number: H857CP
    UPC: 614046630604
    Condition: New
    Weight: 5.84 LBS
    Pack of 8
    $485.99
    Adding to cart… The item has been added

    Have questions?

    Ask an Expert
    Sealed Power Engine Piston Set P/N:H857CP (Pack of 8)
    Sealed Power Engine Piston Set P/N:H857CP (Pack of 8)
    $485.99
    $485.99

    Sealed H857CP engine piston for the 1999-2003 Chevrolet Silverado 2500 V8 6.0L and other vehicles seals the cylinder and passes combustion force to the connecting rod. It is a cast piston set with a recessed head.

    • Helps improve cylinder sealing for less blow-by
    • Retains standard ring gaps in the top groove
    • DUROSHIELD skirt-coated piston
    • Moly-graphite coating reduces friction for higher fuel economy
    • Helps prevent damage from inadequate lubrication on start-up

    Quick facts

    • Part: Sealed H857CP engine piston
    • Fits: 1999-2003 Chevrolet Silverado 2500 V8 6.0L and other vehicles
    • Material: Hypereutectic
    • Condition: New

    Worn pistons and rings can show up as blow-by, oil burning or lower compression. Worn rings, a scored cylinder wall or a leaking head gasket can be behind those signs too, so find the cause before buying pistons. The 6.0L V8 takes eight, one per cylinder.

    Fits

    The 2001-2003 GMC Sierra 1500 V8 6.0L and the 2001-2003 GMC Yukon V8 6.0L are also a fit for this piston, along with other vehicles.

    Specifications

    Fit and size

    • Quantity per vehicle: 8
    • Bore diameter: 4.0000 in (101.6 mm)
    • Piston pin outside diameter: 0.9451 in (24.006 mm)
    • Compression height: 1.325 in
    • Pin offset: 0.03 in (0.762 mm)
    • Ring thickness: top 1.50 mm, second 1.50 mm, oil 3.00 mm
    • Oversized: No

    Build and materials

    • Construction: cast piston set
    • Piston material: Hypereutectic
    • Piston head type: Recessed
    • Skirt coating: DUROSHIELD
    • Country of origin: Mexico
    • Condition: New

    In the box

    The engine piston set. Assembly lubricant is not included.

    Interchange: P3080(8)STD
    TC3426 · P3160 · 88894003 · 89017237

    This part cross-references / interchanges with the following part numbers:

    TC3426, P3160, P3080(8)STD, 88894003, 89017237

    Frequently Asked Questions

    Will the Sealed H857CP piston fit a 1999-2003 Chevrolet Silverado 2500 V8 6.0L?

    Yes. Sealed H857CP fits the 1999-2003 Chevrolet Silverado 2500 V8 6.0L and takes eight pistons, one per cylinder. For a different truck or van, look up your vehicle in the "Vehicles it fits" section.

    Does this piston set come with assembly lubricant?

    No. Assembly lubricant is not included with the Sealed H857CP piston set, so it needs to be bought separately.

    What bore diameter and pin size do these hypereutectic pistons use?

    The bore diameter is 4.0000 in (101.6 mm) and the piston pin outside diameter is 0.9451 in (24.006 mm). The pistons are standard size, not oversized.

    Why do these pistons have a moly-graphite coating?

    The moly-graphite coating cuts friction, which supports fuel economy, and helps protect against damage when lubrication is inadequate at start-up.

    Does Sealed H857CP replace TC3426?

    Yes. TC3426 is on the Interchange line as a number this Sealed H857CP piston replaces.
