Dana/Spicer 10113216 front drive shaft for the 2007-2017 Jeep Wrangler and other vehicles carries torque from the transfer case to the front axle.
- Spicer 1350 series with a T-case yoke
- Steel construction for increased strength
- Extra thick tubing for added durability on the trail
- Slip assembly at the transfer case to minimize impacts and contamination
- Bearings, cups and cones selected for each position and application
- Oil seals that guard against leaks and contamination
Quick facts
- Part: Dana/Spicer 10113216 drive shaft
- Also called: drive shaft assembly
- Fits: 2007-2017 Jeep Wrangler and other vehicles
- Position: Front
- Material: Steel
- Condition: New
Vibration at highway speed, a clunk when you take up drive, or oil or grease around a joint can mean a worn drive shaft. Before you replace it, rule out a worn or loose transfer case yoke and out-of-balance tires or wheels, since those can produce similar vibration.
Fits
This front drive shaft fits the 2007-2017 Jeep Wrangler and the 2018 Jeep Wrangler JK. The 2007-2017 Jeep Wrangler takes one, and so does the 2018 Jeep Wrangler JK.
Specifications
Fit and size
- Position: Front
- Series: 1350
- Transfer case end: T-case yoke
- Quantity per vehicle: 1
Build and materials
- Material: Steel
- Tubing: extra thick
- Slip assembly: at the transfer case
- Condition: New
- Country of origin: United States
In the box
One drive shaft assembly kit with the hardware needed for a bolt-in installation, including sealant, snap rings, a gasket and shims.
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Is this the front drive shaft for a 2012 Jeep Wrangler?
Yes. Dana/Spicer 10113216 fits the 2007-2017 Jeep Wrangler, which includes model year 2012, and the vehicle takes one.
Is this the 2007-2017 Jeep Wrangler drive shaft, and does it also fit the 2018 Jeep Wrangler JK?
Yes. Dana/Spicer 10113216 is a front drive shaft for the 2007-2017 Jeep Wrangler and it also fits the 2018 Jeep Wrangler JK.
What series is this Dana/Spicer drive shaft?
This drive shaft is a Spicer 1350 series with a T-case yoke. It is made of steel and has extra thick tubing.
What parts come with the Dana/Spicer 10113216 kit?
The kit comes with the hardware needed for a bolt-in installation, including sealant, snap rings, a gasket and shims.
What does the slip assembly at the transfer case do on this drive shaft?
The slip assembly sits at the transfer case end of the shaft. It is one of the trail-oriented upgrades, designed to minimize impacts and contamination.
