DANA SPICER CHASSIS 5-1200X universal joint for the 1968-1969 Ford Mustang and other vehicles connects two driveline shafts and lets them turn at an angle. It is tested and validated to rigorous OE specifications.
- S55 Series greaseable universal joint
- Greaseable design with a lube fitting in the cross for easy service
- Seal technology that extends the life of the grease
- Steel joint with ISR-style bearing caps and an internal snap ring
Quick facts
- Part: DANA SPICER CHASSIS 5-1200X universal joint
- Fits: 1968-1969 Ford Mustang and other vehicles
- Material: Steel
- Condition: New
A worn universal joint can show up as a clunk when you shift or pull away, vibration that builds with speed, or a dry, rusty bearing cap. A bent driveshaft or other driveline wear can give similar symptoms, so find the cause before you replace the joint. Once the old joint is out, measure its bearing cap diameter and length against the specs below.
Fits
The 1968-1969 Ford Mustang, the 1987-1991 Mercury Colony Park and the 1980-1988 Mercury Cougar are among the vehicles this DANA SPICER CHASSIS universal joint fits. This listing is one joint, and a 1968-1969 Ford Mustang takes one. If your car is not named here, search the "Vehicles it fits" section for your own year and model.
Specifications
Fit and size
- Quantity per application: 1
- Bearing cap diameter: 1.062 in (26.975 mm) each
- Length (A and B): 2.375 in (60.3 mm) each
Build and materials
- Series: S55
- Type: ISR style, round bearing caps with ISR groove
- Snap ring: internal, included
- Grease fitting: one straight lube fitting in the cross, grease zerk included
- Material: Steel
- Condition: New
- Country of origin: United States
In the box
One universal joint with snap ring and grease zerk. Mounting hardware is not included, so plan on new fasteners.
Product information is for general reference and may contain errors. See our Disclaimer.
Frequently Asked Questions
Does the DANA SPICER CHASSIS 5-1200X fit a 1968-1969 Ford Mustang?
Yes. The DANA SPICER CHASSIS 5-1200X universal joint fits the 1968-1969 Ford Mustang, which takes one. For other years and models, look in the "Vehicles it fits" section.
Does the 5-1200X come with a grease zerk and snap ring?
Yes. This universal joint includes a grease zerk and a snap ring. Mounting hardware is not included.
What size are the bearing caps on the DANA SPICER CHASSIS 5-1200X?
The DANA SPICER CHASSIS 5-1200X has bearing caps 1.062 in (26.975 mm) in diameter, and its length A and B are each 2.375 in (60.3 mm).
Could vibration that builds with speed come from a worn S55 universal joint?
It can, since vibration that rises with speed is a sign of a worn joint. A clunk when you shift or pull away is another sign.
Does this greaseable universal joint have special seals?
Yes. Its seal technology is designed to extend the life of the grease, and the greaseable design allows easy service.
