Standard Ignition ALS2800 rear left tire pressure monitoring system (tpms) sensor for the 2015-2020 Honda Fit reads wheel speed for the vehicle's electronic safety systems. It is an ABS speed sensor that bolts on at the wheel and plugs into the vehicle harness.
- Synthetic material made to withstand harsh operating conditions
- Location grommets and wire clips come on the harness for mounting and routing
- Tested on vehicles for proper fit and correct integration with electronic safety systems
- Sealed connector protects the connection in harsh conditions
Quick facts
- Part: Standard Ignition ALS2800 tire pressure monitoring system (tpms) sensor
- Fits: 2015-2020 Honda Fit
- Position: Rear left
- Material: Synthetic
- Condition: New
A lit ABS warning light can mean the sensor or its wiring needs attention, but other faults can light it too. Where you can see the harness and connector with the engine off, look for chafing, cracks or corrosion first, and leave signal testing to a shop. The rear axle takes one sensor at each wheel; this listing is the rear left, and the right side is a separate part.
Fits
This sensor fits the 2015-2020 Honda Fit at the rear left wheel.
Specifications
Fit and size
- Position: rear left
- Quantity per application: 1
- Mounting: bolt mount at the wheel, 1 bolt hole
- Harness length: 28 in (710 mm)
Build and materials
- Material: synthetic
- Connector: 1 rectangular female connector
- Terminals: 2 male pin terminals
- Condition: new
- Country of origin: China
In the box
One sensor with its harness, location grommets and wire clips. Mounting hardware is not included, so plan on a new bolt, since the old one may not be reusable.
Frequently Asked Questions
Which tire pressure sensor for the 2015-2020 Honda Fit is Standard Ignition ALS2800?
Standard Ignition ALS2800 is the rear left sensor for the 2015-2020 Honda Fit. It is built as an ABS speed sensor with a bolt mount and a 28-inch harness.
Does the ALS2800 sensor come with its mounting bolt?
No. Mounting hardware is not included with Standard Ignition ALS2800, so the bolt is bought separately. The harness does carry location grommets and wire clips.
How long is the harness on this rear left ABS speed sensor?
The harness is 28 inches (710 mm) long. It ends in a rectangular female connector with two male pin terminals.
What can a failing rear wheel speed sensor look like?
A lit ABS warning light, a chafed harness or a corroded connector can mean the sensor needs attention. A shop can test the signal to confirm.
What is this ABS speed sensor made of?
The sensor is made of synthetic material built to withstand harsh operating conditions. Its connector is sealed for protection in those conditions.
