Dorman 524-453 front left lower control arm with ball joint for the 2010-2016 Cadillac SRX connects the wheel assembly to the chassis. This Dorman control arm holds the ball joint that lets the wheel pivot for steering and suspension travel.
- Dorman suspension control arm in standard replacement grade
- Ball joint and bushings come pre-installed, saving time and labor
- Steel control arm, casting/forged type, with rubber bushings
- Additional coatings resist rust and corrosion
- Pre-greased, with no grease fitting
- Evaluation and testing process aimed at a smooth ride and directional stability
Quick facts
- Part: Dorman 524-453 control arm with ball joint
- Also called: control arm and ball joint assembly
- Fits: 2010-2016 Cadillac SRX
- Position: Front left lower
- Material: Steel control arm, rubber bushings
- Condition: New
A clunk over bumps, loose steering or uneven front tire wear can mean a worn control arm or ball joint. Worn sway bar links, struts, tie rod ends or a wheel bearing can be behind the same signs, so find the cause before buying. If this arm is the cause, it replaces the worn one.
Fits
This is a direct replacement for the original equipment on the 2010-2016 Cadillac SRX. This listing is one arm for the front left; the front right is a separate part, and the two sides are normally replaced together.
Specifications
Fit and size
- Position: front left lower
- Quantity per vehicle: 1 for this side
- Mounting hole diameter: 12.3 mm
- Ball joint thread diameter: 14 mm
- Maximum width: 288.5 mm
- Maximum length: 237 mm
Build and materials
- Control arm material: steel
- Control arm type: casting/forged
- Bushing material: rubber
- Ball joint stud: threaded
- Ball joint and bushings: installed
- Grade: standard replacement
- Condition: new
- Country of origin: Taiwan
In the box
One control arm with ball joint and bushings installed, plus mounting hardware. This listing holds one arm, and the front left side of the 2010-2016 Cadillac SRX takes one.
Interchange: TC9482 · CA14603 · 20928344 · 209288344 · 22833484 · 22979575 · RK622088 · GS501165 · CMS501165 · 2607525 · 5CB50382 · SK622088 · 1503069
This part cross-references / interchanges with the following part numbers:
TC9482, CA14603, 20928344, 209288344, 22833484, 22979575, RK622088, GS501165, CMS501165, 2607525, 5CB50382, SK622088, 1503069
Frequently Asked Questions
Is this Dorman lower control arm the right one for the 2010-2016 Cadillac SRX?
Yes, Dorman 524-453 is the front left lower control arm with ball joint for the 2010-2016 Cadillac SRX; the front right side is a separate part.
Does the Dorman suspension control arm and ball joint assembly come pre-greased?
Yes. This Dorman 524-453 arm is pre-greased and has no grease fitting.
Do the Dorman control arm bushings come installed on this arm?
Yes. The rubber bushings are pre-installed on this arm, and the ball joint is installed as well.
What can a clunk over bumps mean on a front lower control arm?
A clunk over bumps, loose steering or uneven front tire wear can mean worn bushings or a worn ball joint. With the engine off, you can look at the rubber bushings for cracks or tears.
What size is the ball joint thread on this front left lower control arm?
The ball joint stud is threaded, with a thread diameter of 14 mm.
