Harmonic Balancer for 1990-1993 Honda Accord & More - PowerBond by Dayco PB1189N

Be the first to review this product

$151.99

MPN: PB1189N

Item Package Quantity: 1

Current Stock:

Quantity:

Adding to cart… The item has been added

Have questions?

Ask an Expert

Dayco Engine Harmonic Balancer P/N:PB1189N

$151.99

Description

Quiet crankshaft vibration and keep the accessory belt driving smoothly with the Dayco harmonic balancer PB1189N (Powerbond premium OE-replacement balancer). It's a direct-fit replacement for the 1990-1993 Honda Accord [L4-2.2L] and the 1992-1996 Honda Prelude [L4-2.2L and L4-2.3L]. A harmonic balancer absorbs the torsional twist pulses of the spinning crankshaft while its pulley drives the engine's belt-driven accessories.

Grey iron outer ring: the inertia ring is made of grey iron.
Two integrated serpentine pulleys: Pulley 1 is a 4-groove serpentine pulley (3.780 in / 96.0 mm OD) and Pulley 2 is a 5-groove serpentine pulley (6.693 in / 170.0 mm OD).
Neutral balance: neutrally balanced with no counterweight. Overall outside diameter 6.989 in (177.50 mm), 2.363 in (60.00 mm) overall width, with a 1.182 in (30.00 mm) crank bore.
No timing marks, no crank trigger/exciter plate, no bolt holes, and no Woodruff key or mounting hardware included. Installation instructions are included.

Signs the original balancer may need replacing include a wobbling or separated outer ring, belt squeal or misalignment, and engine vibration. Country of origin: China.

Interchange: 594-068 · DA-222
594068 · DA222 · 102096 · 6005249

Manufacturer's Description

Product Specs

Buyer's Guide

Interchange Part Numbers

This part cross-references / interchanges with the following part numbers:

102096, 594-068, 6005249, DA-222

Frequently Asked Questions

What vehicles does the Dayco PB1189N harmonic balancer fit?

It's a direct-fit replacement for the 1990-1993 Honda Accord [L4-2.2L] and the 1992-1996 Honda Prelude in both the L4-2.2L and L4-2.3L engines. Confirm your engine in the Buyer's Guide tab.

What does a harmonic balancer do?

It dampens the torsional (twisting) vibrations of the spinning crankshaft, and its integrated pulleys drive the engine's belt-driven accessories.

How many pulleys and grooves does this balancer have?

It has two integrated serpentine pulleys: a 4-groove pulley (3.780 in OD) and a 5-groove pulley (6.693 in OD).

Does the PB1189N include mounting hardware or a Woodruff key?

No. Hardware and the Woodruff key are not included, and there is no crank trigger/exciter plate or bolt holes. Installation instructions are included.

What are signs my harmonic balancer needs replacing?

Look for a wobbling or separated outer ring, belt squeal or misalignment, and engine vibration. Diagnose the cause before replacing, since these symptoms can have other sources.
